What makes the Ford Escort NTR-R3 Coilover Kit different from the NTR-R1?

The passive Nitron NTR-R3 has four independent adjusters per corner, covering high speed and low speed compression and rebound. The NTR-R1 has a single adjuster per corner that changes compression and rebound together.

What do the four adjusters on the NTR-R3 control?

High speed compression and rebound handle bumps, ruts and sharp edges, while low speed compression and rebound control body movement from steering, braking and acceleration. Each one can be set without affecting the others.

Does the Mark II Ford Escort NTR-R3 kit use hoses?

No. The kit uses piggyback reservoirs mounted on the dampers, front and rear, so there are no hoses to route.

Are top plates included in the kit?

Yes. Adjustable top plates are included with the kit.

Can I get different spring rates?

Yes. Custom spring rates are available by contacting us directly, and we can help choose a rate for road, rally or track use.

Is an alignment needed after installing the kit?

Yes. A professional alignment is required after installation.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Nitron NTR-R3 Coilover Kit for Mark II Ford Escort

This Ford Escort NTR-R3 Coilover Kit from Nitron is for Mark II owners who have outgrown a single-knob setup. The car made its name in rallying, where the surface can change every few miles, and the same mix of tarmac, gravel and broken lanes is why one fixed damping compromise never suits it. At around 955kg in 1.6 Ghia form and rear-wheel drive, the Mark II reacts quickly to what the dampers are doing. This kit gives each corner four independent adjusters and a piggyback reservoir, front and rear, so you can set body control and bump absorption separately for the road, a stage or a circuit.

Unique Technology

The Nitron Ford Escort NTR-R3 damper is a monotube design pressurized with nitrogen. The piggyback reservoir sits directly on the damper at each corner, so there are no hoses at all to route or protect. Four adjusters cover high speed compression, low speed compression, high speed rebound and low speed rebound. Low speed settings shape how the car pitches, rolls and squats as you steer, brake and accelerate. High speed settings decide how it deals with ruts, curbs and sharp edges. Because each one works on its own, you can tighten the platform without making the car skittish over rough ground.
- Basic Damper Design:
  1. End Eye / Top Mount
  2. Damper Piston & Shim Stack
  3. Shaft / Rod
  4. Floating / Separator Piston
  5. Suspension Oil
  6. Compressed Nitrogen Gas

Bespoke Engineering

Every Ford Escort NTR-R3 kit is hand assembled to order in the UK, and the dampers are built for the car they are going on. Mark II Escorts end up in very different roles, from a carefully kept road car to a gravel rally build, so the standard spring rates are a starting point rather than the only option. If you need something firmer, softer or simply different, contact us directly and we will work out the right rate with you. That flexibility on springs, along with the four-way damping, is what lets one kit be set up so differently from car to car.

Features

Piggyback reservoir type
OEM rear suspension type
16 clicks of high compression
26 clicks of low compression
24 clicks of rebound
Preload adjuster
3-way independent adjustment
Full alloy body
Consists of 4 coilovers, reservoirs, and top mounts
Hand made to order

Specifications

Coilover Type: NTR-R3
Adjustment Type: 3-way independent
Adjustment: 16 clicks of high compression / 26 clicks of low compression / 24 clicks of rebound
Reservoir Type: Piggyback
Rear Suspension Type: OEM
Droplinks Included: No
Recommended Spring Rates:
- FRS – Fast Road Spec:
  - Front: 513lbs/inch (90N/mm)
  - Rear: 225lbs/inch (40N/mm)
- TDS – Track Day Spec:
  - Front: 628lbs/inch (110N/mm)
  - Rear: 275lbs/inch (48N/mm)

Applications

Ford Escort: Mark II | 1975-1980

Other Suspension Kits for Mark II Ford Escort

NTR-R1 Coilover Kit

Notes

Please let us know your Escort Mark II sub-model when ordering; a Bulletproof Automotive specialist will contact you directly if anything further is needed
Custom spring rates also available, please contact us directly here for more information or for a consultation on custom rates
Images used for illustration purposes only; specific details, finishes and end fittings may differ from that shown

Frequently Asked Questions

What makes the Ford Escort NTR-R3 Coilover Kit different from the NTR-R1? The passive Nitron NTR-R3 has four independent adjusters per corner, covering high speed and low speed compression and rebound. The NTR-R1 has a single adjuster per corner that changes compression and rebound together.
What do the four adjusters on the NTR-R3 control? High speed compression and rebound handle bumps, ruts and sharp edges, while low speed compression and rebound control body movement from steering, braking and acceleration. Each one can be set without affecting the others.
Does the Mark II Ford Escort NTR-R3 kit use hoses? No. The kit uses piggyback reservoirs mounted on the dampers, front and rear, so there are no hoses to route.
Are top plates included in the kit? Yes. Adjustable top plates are included with the kit.
Can I get different spring rates? Yes. Custom spring rates are available by contacting us directly, and we can help choose a rate for road, rally or track use.
Is an alignment needed after installing the kit? Yes. A professional alignment is required after installation.

About Nitron Suspension

Nitron Suspension has been at the forefront of precision suspension engineering since 1998, founded by Guy Evans with the goal of building high-performance shocks for enthusiasts and professionals alike. Over 200 dealers now carry Nitron products across Europe, Asia, the US, Australasia, and Africa. In 2008, the company moved into a dedicated facility in the UK’s Motorsport Valley, adding dynamometers, 5-axis CNC machines, and 3D CAD capabilities to support both growing demand and continued product development. A second expansion came in 2023 with a new office in Murrieta, California. The team behind every Nitron product draws from deep backgrounds in machining, materials technology, hydraulics, bike engineering, and F1 racing, with many engineers bringing firsthand experience as competitive drivers and riders. That depth of knowledge across both the technical and competitive sides of motorsport shapes every product Nitron develops.
