Do the Hipermax R Coilovers for FK8 include the damper error canceller?

No. HKS notes that the FK8 displays an error once the stock dampers are removed, and it lists the canceller as a separate optional part. Order the canceller alongside the kit if you want to avoid the warning, and confirm availability with Bulletproof Automotive before installation day.

Will this kit fit a Civic that is not a Type R?

No. HKS states that this kit is for the Civic Type R and cannot be fitted to other Civic grades. It is listed for the FK8 Civic Type R with the K20C1 engine from 2017 to 2021, and the newer FL5 Type R uses its own HKS part number, 80310-AH005C.

Why is the front spring firmer than the rear?

HKS sets the Hipermax R Coilovers for FK8 up with a 118 N/mm front spring and a 98 N/mm rear spring. HKS does not publish its reasoning, but on a front-drive car a firmer front rate is a common way to support the nose under braking and cornering while keeping the rear responsive.

Is the Hipermax R suitable for a daily driven FK8?

Yes. HKS aimed the Hipermax R line at drivers who focus on track performance but do not want to give up comfort in everyday use. The 30 damping steps let an FK8 owner soften the car for commuting, though the spherical bearing upper mounts will pass more road feel into the cabin than the factory mounts.

How does the Hipermax R compare with the HIPERMAX S?

HKS also offers the HIPERMAX S line as a more street-focused coilover kit. The Hipermax R is the choice for Civic Type R owners who put circuit performance first while still expecting a usable road car. Ask Bulletproof Automotive about current HIPERMAX S availability for the FK8.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

HKS Hipermax R Coilovers for FK8 Honda Civic Type R

The HKS Hipermax R Coilovers for FK8 are built for the K20C1 turbocharged, front-drive Honda Civic Type R and for no other Civic grade, a restriction HKS spells out in its own application notes. HKS runs a firmer 118 N/mm front spring over a 98 N/mm rear, both 150mm straight springs, and gives each corner 30 damping steps. The FK8 already handles well from the factory, so this kit makes most sense for owners doing regular track days or time attack rounds who want real adjustability. Buyers after a lowered look alone will find it more than they need.

Features

Single-tube dampers with a large-diameter piston for stable, consistent damping force
30-step damping adjustment front and rear for tuning the Type R between road and circuit use
Pillow ball upper mounts front and rear, listed by HKS as spherical bearings
Shock-body length adjustable construction, so ride height is set on the damper body
SRF high-viscosity damper oil that HKS developed to resist heat sag
LVS springs from high-strength wire, with a front-biased rate split for the front-drive layout

Specifications

Spring rate, front: 118 N/mm (12.0 kgf/mm)
Spring rate, rear: 98 N/mm (10.0 kgf/mm)
Free length: 150mm front and rear
Spring type: Straight, front and rear
Damping adjustment: 30 steps front and rear
Upper mount: Spherical bearing, front and rear

Applications

Honda Civic Type R: FK8 | 2017-2021 | K20C1

Notes

Removing the factory dampers brings up an error on the FK8 dash. HKS lists a canceller as an optional part to prevent the error, and it is not included with this kit.
HKS states that this kit is for the Civic Type R only and cannot be fitted to other Civic grades
Have the Hipermax R Coilovers for FK8 installed by a qualified shop and follow up with a full alignment
Specification data is taken from the HKS Japan product database for part number 80310-AH003

Frequently Asked Questions

Do the Hipermax R Coilovers for FK8 include the damper error canceller? No. HKS notes that the FK8 displays an error once the stock dampers are removed, and it lists the canceller as a separate optional part. Order the canceller alongside the kit if you want to avoid the warning, and confirm availability with Bulletproof Automotive before installation day.
Will this kit fit a Civic that is not a Type R? No. HKS states that this kit is for the Civic Type R and cannot be fitted to other Civic grades. It is listed for the FK8 Civic Type R with the K20C1 engine from 2017 to 2021, and the newer FL5 Type R uses its own HKS part number, 80310-AH005C.
Why is the front spring firmer than the rear? HKS sets the Hipermax R Coilovers for FK8 up with a 118 N/mm front spring and a 98 N/mm rear spring. HKS does not publish its reasoning, but on a front-drive car a firmer front rate is a common way to support the nose under braking and cornering while keeping the rear responsive.
Is the Hipermax R suitable for a daily driven FK8? Yes. HKS aimed the Hipermax R line at drivers who focus on track performance but do not want to give up comfort in everyday use. The 30 damping steps let an FK8 owner soften the car for commuting, though the spherical bearing upper mounts will pass more road feel into the cabin than the factory mounts.
How does the Hipermax R compare with the HIPERMAX S? HKS also offers the HIPERMAX S line as a more street-focused coilover kit. The Hipermax R is the choice for Civic Type R owners who put circuit performance first while still expecting a usable road car. Ask Bulletproof Automotive about current HIPERMAX S availability for the FK8.

About HKS

HKS is a Japanese performance engineering brand founded in 1973 and headquartered in Fujinomiya, Shizuoka, with a long-standing reputation for developing high-quality aftermarket parts and motorsport-proven technology for enthusiast and professional applications. Known for innovations in turbocharging and engine performance, HKS produces a broad range of components including exhaust systems, turbo kits, electronics / engine management, and suspension solutions, with product development heavily influenced by decades of involvement in racing disciplines such as circuit time attack, drag, and drifting.
