Which DC5 models do the Black Series Coilovers for DC5 cars fit?

The manufacturer lists the Black Series Coilovers for DC5 cars for the Integra Type R, and its US distributor files them under the Acura RSX for Type S and Type R. A separate kit is catalogued for the Japanese-market Integra iS and Type S, so confirm your car with Bulletproof Automotive first.

How low can the car go?

The manufacturer recommends lowering of about 25 to 45mm compared with stock. Within that range the revised bracket keeps the tie rod angle correct with the factory tie rods. Going beyond the recommended range is possible on a full-length adjustable body, but the tie rod claim no longer applies.

Are the springs too stiff for street driving?

They are firmer than a typical street coilover by design. The manufacturer calls the Black Series Coilovers for DC5 cars a high-spec street damper with an emphasis on sports driving. The 15-step damping adjustment lets you soften the ride for the road and firm it up for the circuit.

Can the dampers be rebuilt?

Yes. The manufacturer states that every version of the Black Series Damper RS can be overhauled, and replacement damper cartridges are offered individually for the front and rear, so worn dampers do not mean replacing the whole kit. Plan a rebuild based on how hard the car is used.

Will I need any other parts to install them?

Usually not. The kit includes the front camber-adjustable pillow upper mounts and both adjustment wrenches, and the stock tie rods can stay. On a car with high-caster lower arms, the front upper mounts must be swapped from side to side.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

J’s Racing Black Series Coilovers for DC5 Honda Integra Type R and Acura RSX

J’s Racing’s Black Series Coilovers for DC5 Integra Type R owners are the first coilover kit the Osaka tuner designed entirely in-house, catalogued as the Black Series Damper RS and developed from more than 20 years of racing. Spring rates of 12 kg/mm front and 14 kg/mm rear are higher than a typical street kit, so the car sits lower with a front-to-rear balance chosen for cornering, and 15 damping steps let you tune for each event. It suits a driver who does real sports driving; a gentle commuter will find the rates firmer than needed.

Design and Performance

The full-length adjustable bodies use a shortened case and stroke, so the car can be lowered without giving up bump travel. Dampers are monotube, with a large-diameter inverted cylinder where a strut needs extra rigidity.

Features

Full-length adjustable design that keeps bump stroke when lowered
Monotube dampers with 15-step damping adjustment
Front pillow-ball upper mounts with camber adjustment
Revised bracket position for the stock tie rods
Ride height and damping wrenches supplied

Specifications

Spring rate, front: 12 kg/mm
Spring rate, rear: 14 kg/mm
Spring inner diameter: 65mm
Spring free length: 150mm front and rear
Recommended lowering: about 25 to 45mm versus stock
Front camber adjustment: up to about 3.5 degrees
Damping adjustment: 15 steps

Applications

Acura RSX Type S: DC5 | 2002-2006 | 2.0L K20A2
Honda Integra Type R: DC5 | 2001-2006 | 2.0L K20A

Notes

On cars with high-caster lower arms, the front upper mounts must be swapped left to right
Turn the damping dials gently, because the supplied wrench can apply enough force to damage the shaft
Check every bolt and nut regularly after installation, and before each circuit session
J’s Racing Japan specifies this kit for the DC5 Integra Type R; the separate RS Damper Kit for the DC5 Integra iS and Type S covers those models
J’s Racing USA lists the kit under the Acura RSX and names it for both Type S and Type R
Shipped from Japan via J’s Racing USA; Bulletproof Automotive confirms the lead time when you order

Frequently Asked Questions

Which DC5 models do the Black Series Coilovers for DC5 cars fit? The manufacturer lists the Black Series Coilovers for DC5 cars for the Integra Type R, and its US distributor files them under the Acura RSX for Type S and Type R. A separate kit is catalogued for the Japanese-market Integra iS and Type S, so confirm your car with Bulletproof Automotive first.
How low can the car go? The manufacturer recommends lowering of about 25 to 45mm compared with stock. Within that range the revised bracket keeps the tie rod angle correct with the factory tie rods. Going beyond the recommended range is possible on a full-length adjustable body, but the tie rod claim no longer applies.
Are the springs too stiff for street driving? They are firmer than a typical street coilover by design. The manufacturer calls the Black Series Coilovers for DC5 cars a high-spec street damper with an emphasis on sports driving. The 15-step damping adjustment lets you soften the ride for the road and firm it up for the circuit.
Can the dampers be rebuilt? Yes. The manufacturer states that every version of the Black Series Damper RS can be overhauled, and replacement damper cartridges are offered individually for the front and rear, so worn dampers do not mean replacing the whole kit. Plan a rebuild based on how hard the car is used.
Will I need any other parts to install them? Usually not. The kit includes the front camber-adjustable pillow upper mounts and both adjustment wrenches, and the stock tie rods can stay. On a car with high-caster lower arms, the front upper mounts must be swapped from side to side.

About J’s Racing

J’s Racing was established in Osaka in 1989, as VTEC engines and lightweight Civics and Integras were changing what a Honda could do, and it has built parts for Hondas ever since. The company develops engine response, suspension, braking, cooling and aerodynamics together as one system, then proves the parts in time attack, gymkhana, endurance and circuit racing. Its Fit lapped Tsukuba Circuit in 1’00.459, and its naturally aspirated AP1 S2000, the Maou car, became the company’s reference build for the Honda roadster. Every J’s Racing part is designed and tested in Japan, and J’s Racing USA in Carson, California handles distribution in the United States.
