Which cars use this 2ZZ-GE set?

Injector Dynamics lists it for the Lotus Elise and Exige from 2005 and the 2000 to 2005 Toyota Celica GTS, all with the 2ZZ-GE engine. Other Toyota models with the 2ZZ-GE are not part of the listing, so confirm your car with Injector Dynamics before ordering.

Is the ID1750-XDS Fuel Injector Set right for a supercharged Exige?

Yes, when E85 or a large power increase is planned. The ID1750-XDS Fuel Injector Set flows 1728cc per minute per injector, and minimum fuel mass is unchanged from the ID1700 so the engine still idles well. A supercharged car on gasoline at moderate boost may suit the ID1300-XDS better.

Do the injectors connect to the factory 2ZZ wiring directly?

No, unless the wiring already uses USCAR plugs. Each injector has a USCAR connector, and Denso, EV1 or OBD2 wiring needs an Injector Dynamics plug and play adapter, sold separately. The Denso adapter is stocked here, so check the plug on a factory injector first.

Will the car need a new tune?

Yes. The 2ZZ-GE must be recalibrated with the flow rate, offset and short pulse data Injector Dynamics publishes for the 1750. A 1728cc per minute injector on the factory values would over fuel badly at idle and part throttle, so the calibration comes before driving.

What is the warranty?

Injector Dynamics gives one year from purchase against manufacturer defects, conditional on correct fuel and proper filtration. Because the four injectors are flow matched, a single replacement is supplied by Injector Dynamics. A cleaning, inspection and flow test service is also available from its Arizona facility.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Injector Dynamics ID1750-XDS Fuel Injector Set for 2ZZ-GE Lotus Elise, Lotus Exige and Toyota Celica GTS

Injector Dynamics’ ID1750-XDS Fuel Injector Set for the 2ZZ-GE gives the 2005-on Lotus Elise and Exige, and the 2000-2005 Toyota Celica GTS, four 1728cc/min injectors on 60mm bodies with blue 11mm tops. The 30.01 application code covers that high-revving 1.8L four. This is fuel for a supercharged or turbocharged 2ZZ on E85; a naturally aspirated Elise or Celica on gasoline would be better served by a smaller flow class.

Configuration

The 30.01 code marks the 2ZZ-GE application, the 60 is the 60mm body and the 11 is the blue 11mm top. The same engine is offered in the ID1300-XDS and ID2600-XDS flow classes.

Features

ID1750-XDS Fuel Injector Set coded for the 2ZZ-GE
Four 60mm injectors with blue 11mm tops
Rated for ethanol, methanol, MTBE, nitromethane and gasoline
Better balance between cylinders at low pulsewidths than the ID1700

Specifications

Nominal flow: 1728cc/min at 3.0 bar (43.5 psi), E10 certification fuel at 49C (120F)
Maximum differential fuel pressure: 7.0 bar (101.5 psi)
Offset at 43.5 psi: 1169 microseconds at 12 volts
Electrical connector: USCAR
Body length: 60mm
Top: 11mm (blue)

What’s Included

ID1750-XDS fuel injectors with 11mm tops (x4)

Applications

Lotus Elise and Exige: 2005+ | 2ZZ-GE
Toyota Celica GTS: 2000-2005 | 2ZZ-GE

Notes

The injectors carry USCAR plugs; for Denso wiring add the Injector Dynamics USCAR to Denso PnP Adapter, and other connector types need the matching Injector Dynamics adapter
Plan on a recalibration using the Injector Dynamics data for the 1750 before the car is driven
The 2ZZ-GE application is also offered as the ID1300-XDS Fuel Injector Set for the 2ZZ-GE and the ID2600-XDS Fuel Injector Set for the 2ZZ-GE

Frequently Asked Questions

Which cars use this 2ZZ-GE set? Injector Dynamics lists it for the Lotus Elise and Exige from 2005 and the 2000 to 2005 Toyota Celica GTS, all with the 2ZZ-GE engine. Other Toyota models with the 2ZZ-GE are not part of the listing, so confirm your car with Injector Dynamics before ordering.
Is the ID1750-XDS Fuel Injector Set right for a supercharged Exige? Yes, when E85 or a large power increase is planned. The ID1750-XDS Fuel Injector Set flows 1728cc per minute per injector, and minimum fuel mass is unchanged from the ID1700 so the engine still idles well. A supercharged car on gasoline at moderate boost may suit the ID1300-XDS better.
Do the injectors connect to the factory 2ZZ wiring directly? No, unless the wiring already uses USCAR plugs. Each injector has a USCAR connector, and Denso, EV1 or OBD2 wiring needs an Injector Dynamics plug and play adapter, sold separately. The Denso adapter is stocked here, so check the plug on a factory injector first.
Will the car need a new tune? Yes. The 2ZZ-GE must be recalibrated with the flow rate, offset and short pulse data Injector Dynamics publishes for the 1750. A 1728cc per minute injector on the factory values would over fuel badly at idle and part throttle, so the calibration comes before driving.
What is the warranty? Injector Dynamics gives one year from purchase against manufacturer defects, conditional on correct fuel and proper filtration. Because the four injectors are flow matched, a single replacement is supplied by Injector Dynamics. A cleaning, inspection and flow test service is also available from its Arizona facility.

About Injector Dynamics

Injector Dynamics is an Arizona injector specialist and an authorized technical partner of Bosch Motorsport, developing its injectors to its own specification rather than modifying production parts. It introduced slope and offset matching in 2007, and its Dual Slope Matching, developed by engineer Aaron Looft, extends matching into the short pulse widths that boosted and ethanol engines rely on. Its flow benches are built in house and calibrated against a NIST-traceable flow prover. Injector Dynamics supplied the emissions-compliant injectors for the twin-turbo Noble M600, and its injectors were fitted to the first seven-second Nissan GT-R and the first 300 mph motorcycle.
