What is the difference between the Boost Logic Pro Series 5.2 Forged Pistons and the standard set?

Boost Logic sells the standard 5.2 forged piston in 10:1 or 12.5:1 compression, while the Pro Series 5.2 Forged Pistons come at 12.5:1. Boost Logic does not publish a detailed list of design differences between the two, so ask Bulletproof Automotive to confirm details such as included pins before choosing between them.

Which engines do the pistons fit?

Boost Logic lists fitment for every Lamborghini Huracán model and the 2017 and later Audi R8 with the 5.2 liter V10, which is the second-generation 4S R8. First-generation R8 V10 engines are not listed, so owners of those cars should confirm fitment with Bulletproof Automotive before ordering a set.

Why 12.5:1 compression?

Boost Logic uses 12.5:1 on the Pro Series to improve combustion, power delivery and throttle response. A ratio close to the factory figure keeps the engine responsive off boost. Builds planning very high boost pressure may prefer the 10:1 standard piston for more detonation margin, so match the choice to the turbo kit, fuel and tune.

Are wrist pins included?

Boost Logic does not list the contents of the Pro Series set in its description. The standard Boost Logic 5.2 set ships with heavy-duty wrist pins and clips, and Boost Logic sells optional Pro Mod wrist pins in C350 tool steel separately. Confirm with Bulletproof Automotive what ships with this set before ordering pins or rings.

Do I need a professional engine builder to install them?

Yes. Pistons are fitted with the engine disassembled, and the bores should be measured and prepared by the engine builder so that clearances suit forged pistons. Installing the set is part of a full V10 engine build, usually done alongside rods, head gaskets and a calibration planned for the new power level.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Boost Logic Pro Series 5.2 Forged Pistons for LB724 Lamborghini Huracán and 4S Audi R8

Boost Logic’s Pro Series 5.2 Forged Pistons are forged pistons for the Lamborghini Huracán and the 2017 and later Audi R8 5.2-liter V10, set at a 12.5:1 compression ratio. Where the standard Boost Logic 5.2 forged piston is offered in 10:1 or 12.5:1, the Pro Series comes in the higher ratio, which Boost Logic uses for combustion efficiency, power delivery and throttle response. Boost Logic lists fitment for every Huracán model and the R8 5.2 from 2017 on. It suits a build that wants to keep compression close to factory; an engine planned for very high boost may be better served by the 10:1 standard piston.

Features

Precision forged construction balancing strength and weight
12.5:1 compression ratio for response and power delivery
Material selected for strength and heat resistance under hard use, per Boost Logic
Engineered for precise fitment and reduced friction in the 5.2-liter V10

Applications

Audi R8: 4S | 2017-2023 | 5.2L V10
Lamborghini Huracán: LB724 | 2015-2024 | 5.2L V10

Notes

The Pro Series 5.2 Forged Pistons come at 12.5:1; the Boost Logic 5.2 Forged Pistons for LB724 Lamborghini Huracán and 4S Audi R8 (BL 06030407) are offered in 10:1 or 12.5:1
Boost Logic does not state the quantity or list wrist pins, rings or rods with this set; the product photo shows ten pistons, so confirm contents with Bulletproof Automotive before ordering
Optional Boost Logic Pro Mod Wrist Pins for LB724 Lamborghini Huracán and 4S Audi R8 (BL 06030407-PMRP) in C350 tool steel are sold separately
Boost Logic also sells Boost Logic V10 Cylinder Sleeves for LB724 Lamborghini Huracán and Audi R8 (BL 06030408) for block builds that call for them
An engine-build part, fitted with the engine apart

Frequently Asked Questions

What is the difference between the Boost Logic Pro Series 5.2 Forged Pistons and the standard set? Boost Logic sells the standard 5.2 forged piston in 10:1 or 12.5:1 compression, while the Pro Series 5.2 Forged Pistons come at 12.5:1. Boost Logic does not publish a detailed list of design differences between the two, so ask Bulletproof Automotive to confirm details such as included pins before choosing between them.
Which engines do the pistons fit? Boost Logic lists fitment for every Lamborghini Huracán model and the 2017 and later Audi R8 with the 5.2 liter V10, which is the second-generation 4S R8. First-generation R8 V10 engines are not listed, so owners of those cars should confirm fitment with Bulletproof Automotive before ordering a set.
Why 12.5:1 compression? Boost Logic uses 12.5:1 on the Pro Series to improve combustion, power delivery and throttle response. A ratio close to the factory figure keeps the engine responsive off boost. Builds planning very high boost pressure may prefer the 10:1 standard piston for more detonation margin, so match the choice to the turbo kit, fuel and tune.
Are wrist pins included? Boost Logic does not list the contents of the Pro Series set in its description. The standard Boost Logic 5.2 set ships with heavy-duty wrist pins and clips, and Boost Logic sells optional Pro Mod wrist pins in C350 tool steel separately. Confirm with Bulletproof Automotive what ships with this set before ordering pins or rings.
Do I need a professional engine builder to install them? Yes. Pistons are fitted with the engine disassembled, and the bores should be measured and prepared by the engine builder so that clearances suit forged pistons. Installing the set is part of a full V10 engine build, usually done alongside rods, head gaskets and a calibration planned for the new power level.

About Boost Logic

Boost Logic was founded in Austin, Texas in 2003 and made its name with Toyota Supra turbo kits, setting street car records at 6speed record days and the Texas Mile that stood long after the company stopped racing Supras competitively. It designs turbo systems, titanium exhausts, intercoolers and engine components for the Toyota Supra, Porsche 911 Turbo, Nissan GT-R, Ferrari and Lamborghini, and its R35 GT-R builds have trapped over 180 mph in the quarter mile and over 200 mph in the half mile.
