What does installing the Swan Neck UCW Rear Wing Kit for A90 involve?

Expect to drill the trunk lid: the Swan Neck UCW Rear Wing Kit for A90 bolts through it, and a template in the box marks each hole. Machined aluminum plates reinforce the hatch from below, plastic stops pass the load to the body, and Verus Engineering publishes a manual and video. Hatch struts are not included.

How is the swan neck UCW different from the standard UCW wing?

Both use the UCW airfoil and the 500 lb plus rating, but the swan neck version holds the element from above on curved uprights. Verus Engineering says this goose neck mounting raises efficiency and performance compared with its bottom-mount UCW. Choose between them on budget, looks and how much that gain matters.

How does it compare with the Verus V1X wing?

The V1X is the larger wing, rated by Verus Engineering for more than 700 lb of downforce against 500 lb plus for the UCW. Verus says none of its three Supra wings is objectively best, and publishes a comparison video to help owners pick the right one for their car.

Can the wing be tuned to suit my front aero setup?

Yes. The angle of attack adjusts from 0 to 15 degrees so the wing can balance a range of front aero kits, according to Verus Engineering. Start at a low angle, add more as the front gains downforce, and check the balance on track after each change.

How long does the swan neck wing take to ship?

Verus Engineering assembles UCW wings to order and ships them within 5 business days of the order unless it states otherwise. Choose FFV carbon endplates or the standard carbon endplates when ordering, at the same price. The kit arrives complete with uprights, mounts, plates, trunk stops, template and hardware.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Verus Engineering Swan Neck UCW Rear Wing Kit for A90 Toyota GR Supra

Verus Engineering’s Swan Neck UCW Rear Wing Kit for A90 Toyota GR Supra hangs the UCW airfoil from machined swan neck uprights fixed to its upper surface, leaving the underside of the element clear. Verus says this goose neck layout makes the wing more efficient and effective than its bottom-mount UCW, with the same factory trunk mounting and 500 lb plus rating. It suits a track car that needs a large step in rear downforce to match a strong front aero package.

Design

The airfoil fills a build volume derived from the larger Verus V1X, refined with the ANSYS adjoint solver and checked in CFD for clean airflow on the car, and Verus reports close agreement between its CFD and track testing. The 2×2 twill pre-preg carbon element is autoclave cured under a high-gloss clear, and Verus designs and builds the wing in Indianapolis.

Features

Swan neck uprights keep the underside of the element clean
Angle of attack adjusts from 0 to 15 degrees
Generates and withstands more than 500 lb of downforce
Billet uprights, trunk mounts and support plates
Load-transferring trunk stops

What’s Included

Rear wing element assembly
Machined aluminum swan neck uprights (x2)
Machined aluminum trunk mounts (x2)
Machined aluminum hatch strengthening plates (x2)
Carbon endplates, FFV or standard (x2)
Hard plastic trunk stops
Drill template
Hardware kit

Applications

Toyota GR Supra: A90 | 2020-2026

Notes

The trunk lid is drilled for the uprights, guided by the drill template in the kit and the Verus install manual and video
Verus assembles each Swan Neck UCW Rear Wing Kit for A90 to order and dispatches it within 5 business days unless it advises otherwise
Hatch struts are not included; Verus recommends upgraded struts if the trunk will not stay open
Balance the front with the Front Splitter Kit for A90 Toyota GR Supra and the Dual Element Dive Plane Kit
Other Verus options: the UCW Rear Wing Kit and the Swan Neck V1X Rear Wing Kit
See every Verus Engineering part for the A90 Toyota GR Supra
Verus covers its parts with a 1-year limited warranty against manufacturing defects

Frequently Asked Questions

What does installing the Swan Neck UCW Rear Wing Kit for A90 involve? Expect to drill the trunk lid: the Swan Neck UCW Rear Wing Kit for A90 bolts through it, and a template in the box marks each hole. Machined aluminum plates reinforce the hatch from below, plastic stops pass the load to the body, and Verus Engineering publishes a manual and video. Hatch struts are not included.
How is the swan neck UCW different from the standard UCW wing? Both use the UCW airfoil and the 500 lb plus rating, but the swan neck version holds the element from above on curved uprights. Verus Engineering says this goose neck mounting raises efficiency and performance compared with its bottom-mount UCW. Choose between them on budget, looks and how much that gain matters.
How does it compare with the Verus V1X wing? The V1X is the larger wing, rated by Verus Engineering for more than 700 lb of downforce against 500 lb plus for the UCW. Verus says none of its three Supra wings is objectively best, and publishes a comparison video to help owners pick the right one for their car.
Can the wing be tuned to suit my front aero setup? Yes. The angle of attack adjusts from 0 to 15 degrees so the wing can balance a range of front aero kits, according to Verus Engineering. Start at a low angle, add more as the front gains downforce, and check the balance on track after each change.
How long does the swan neck wing take to ship? Verus Engineering assembles UCW wings to order and ships them within 5 business days of the order unless it states otherwise. Choose FFV carbon endplates or the standard carbon endplates when ordering, at the same price. The kit arrives complete with uprights, mounts, plates, trunk stops, template and hardware.

About Verus Engineering

Verus Engineering designs aerodynamic and performance parts in Indianapolis, Indiana. Two engineers founded it in late 2014 as Velox Motorsports and renamed it in 2017 after a trademark dispute; verus is Latin for true or complete. Each design starts from a 3D scan of the car, is developed with CFD and finite element analysis and is validated on track, across more than 20 platforms from the GR86 to the C8 Corvette.
