Does the Air Oil Separator for ZN6 include a drain valve?

No. The Air Oil Separator for ZN6 ships with the assembled can, four coalescent filters, a left-hand-drive bracket, rubber hose and hardware, but no drain valve. The bottom of the can accepts a Subaru Fumoto drain valve, sold separately, which makes draining the collected oil quick and clean at each service.

Why does oil in the intake matter on the 86 and BRZ?

Oil carried into the intake by crankcase ventilation reduces the octane of the charge, which Verus Engineering notes can lead to detonation, a reduction in power and carbon build-up. The AOS removes that oil before the crankcase air returns to the intake, using four 5 micron coalescent filters, internal baffles and stainless mesh.

Will the Verus AOS fit a right-hand-drive GT86?

No. The sheet aluminum bracket supplied with the kit is designed for left-hand-drive FR-S, BRZ and 86 models only, which covers every car sold new in the United States. Owners of right-hand-drive cars should contact Verus Engineering before ordering, since the bracket is the part that locates the separator in the engine bay.

Are the drain back and coolant kits included?

No. Verus Engineering sells the AOS drain back kit and the AOS coolant add-on kit as optional extras, separate from this separator, so an owner can adapt the unit to a specific setup. The base kit includes the assembled AOS, four 5 micron coalescent filters, internal baffling, stainless mesh, the bracket, rubber hose and the hardware bag.

Which color should I choose for the AOS?

Verus Engineering anodizes the separator in blue, black or red, and the choice is purely cosmetic since all three share the same 6061-T6 body, filters and internals. Verus notes that anodized parts can fade over time from engine bay heat, so a car that sees long track sessions may show some change in color.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Verus Engineering Air Oil Separator for ZN6 Toyota 86, Scion FR-S and ZC6 Subaru BRZ

Verus Engineering’s Air Oil Separator for ZN6 Toyota 86, Scion FR-S and ZC6 Subaru BRZ keeps crankcase oil out of the intake, where it lowers octane and can lead to detonation, lost power and carbon build-up. Four 5 micron coalescent filters, one on each inlet and outlet, work with internal baffling and stainless mesh to strip oil from the crankcase air. The body is CNC machined from 6061-T6 aluminum with Mil-spec O-ring bosses and CNC laser engraving, then anodized for corrosion resistance. It earns its place on a car that sees track days or regular hard driving.

Options and Draining

The bottom of the can accepts a Subaru Fumoto drain valve, and Verus offers an AOS drain back kit and an AOS coolant add-on kit to tailor the unit to the car. The supplied sheet aluminum bracket is made for left-hand-drive cars, and 3/8 inch and 1/2 inch rubber hose comes in the box.

Features

Four 5 micron coalescent filters, internal baffling and stainless mesh
CNC machined 6061-T6 aluminum body with Mil-spec O-ring bosses
Anodized in blue, black or red, with CNC laser engraving
Base accepts a Subaru Fumoto drain valve
Made in the U.S.A.

What’s Included

Assembled AOS with internal baffling and stainless mesh
Coalescent filters (x4)
Sheet aluminum mounting bracket, left-hand drive
3/8 inch rubber hose
1/2 inch rubber hose
Hardware bag with every part needed for the install

Applications

Scion FR-S: ZN6 | 2013-2016
Subaru BRZ: ZC6 | 2013-2020
Toyota 86: ZN6 | 2017-2020

Notes

The included bracket fits left-hand-drive cars only
The Fumoto drain valve, AOS drain back kit and AOS coolant add-on kit are sold separately
Engine bay heat can fade the anodized color over time
Verus publishes an install manual and an install video for the Air Oil Separator for ZN6
See every Verus Engineering part for the ZN6 Toyota 86, Scion FR-S and ZC6 Subaru BRZ
Verus covers its parts with a 1-year limited warranty against manufacturing defects

Frequently Asked Questions

Does the Air Oil Separator for ZN6 include a drain valve? No. The Air Oil Separator for ZN6 ships with the assembled can, four coalescent filters, a left-hand-drive bracket, rubber hose and hardware, but no drain valve. The bottom of the can accepts a Subaru Fumoto drain valve, sold separately, which makes draining the collected oil quick and clean at each service.
Why does oil in the intake matter on the 86 and BRZ? Oil carried into the intake by crankcase ventilation reduces the octane of the charge, which Verus Engineering notes can lead to detonation, a reduction in power and carbon build-up. The AOS removes that oil before the crankcase air returns to the intake, using four 5 micron coalescent filters, internal baffles and stainless mesh.
Will the Verus AOS fit a right-hand-drive GT86? No. The sheet aluminum bracket supplied with the kit is designed for left-hand-drive FR-S, BRZ and 86 models only, which covers every car sold new in the United States. Owners of right-hand-drive cars should contact Verus Engineering before ordering, since the bracket is the part that locates the separator in the engine bay.
Are the drain back and coolant kits included? No. Verus Engineering sells the AOS drain back kit and the AOS coolant add-on kit as optional extras, separate from this separator, so an owner can adapt the unit to a specific setup. The base kit includes the assembled AOS, four 5 micron coalescent filters, internal baffling, stainless mesh, the bracket, rubber hose and the hardware bag.
Which color should I choose for the AOS? Verus Engineering anodizes the separator in blue, black or red, and the choice is purely cosmetic since all three share the same 6061-T6 body, filters and internals. Verus notes that anodized parts can fade over time from engine bay heat, so a car that sees long track sessions may show some change in color.

About Verus Engineering

Verus Engineering designs aerodynamic and performance parts in Indianapolis, Indiana. Two engineers founded it in late 2014 as Velox Motorsports and renamed it in 2017 after a trademark dispute; verus is Latin for true or complete. Each design starts from a 3D scan of the car, is developed with CFD and finite element analysis and is validated on track, across more than 20 platforms from the GR86 to the C8 Corvette.
