Why buy the LSD Differential Assembly for AP1 instead of the separate parts?

Because the setup is done. Spoon fits its 4.44 final gear and LSD into a new Honda differential, then adjusts, balances and checks the whole unit before it ships. Buying the LSD Differential Assembly for AP1 removes the need to find a shop that can set gear mesh and preload correctly, and the original differential stays intact as a spare.

How does the 4.44 ratio change the feel of the car?

Each gear is about 8 percent shorter than with the factory 4.10 final drive, so the car pulls harder in every ratio and reaches the top of each gear sooner. The flip side is higher engine speed at a steady highway cruise. On a track or a tight road the trade is easy to accept, while on long commutes it is noticeable.

Is the differential new or rebuilt?

Spoon builds it from a new genuine Honda differential assembly, not a used core. The Spoon final gear and Spoon LSD are fitted inside, and the unit is washed, measured and assembled to Spoon specification. That gives a fresh housing and bearings alongside the upgraded internals, which matters on a car that may be two decades old.

Does it fit a 2004 or 2005 US S2000?

No. Those cars carry the 2.2L F22C1, and Go Tuning, the sole US distributor for Spoon, assigns them to the AP2 version of this assembly. This AP1 unit is sold for 2000 to 2003 model year US cars, and Spoon registers it for JDM AP1 cars with the F20C built from 1999 to 2005.

How involved is installation?

It is a lift job for a shop that works on rear-drive cars. The factory differential comes out with the axles and propeller shaft disconnected, and the Spoon unit goes in as a complete assembly weighing a listed 33 kg. Refill with fresh differential fluid of the grade the installer recommends for a limited-slip unit.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Spoon Sports LSD Differential Assembly for AP1 Honda S2000 with 4.44 Final Gear

The Spoon Sports LSD Differential Assembly for AP1 Honda S2000 arrives as a complete rear differential: a new genuine Honda unit that Spoon opens, fits with its own 4.44 final gear and limited-slip differential, then washes, measures, balances and closes up to its own specification. That last step is the reason to buy it whole. Setting gear mesh and bearing preload on a final drive is specialist work, and here it has already been done by Spoon technicians in Tokyo. Against the factory 4.10 ratio, the 4.44 gear is roughly 8 percent shorter, so every gear multiplies torque harder and the car pulls with more urgency out of slow corners, while the LSD puts that drive down evenly on the exit. At a listed 33 kg, it is aimed at an AP1 that sees regular circuit days; for a cruiser that rarely leaves the highway, the higher engine speed at a cruise will feel like a cost rather than a gain.

Features

Built on a new genuine Honda differential assembly
Spoon 4.44 final gear in place of the factory 4.10 ratio
Spoon limited-slip differential fitted inside
Washed, measured, adjusted and balanced by Spoon before dispatch
Arrives as one unit with the gear setup already done

Applications

Honda S2000: AP1 | 1999-2005 | 2.0L F20C

Notes

The LSD Differential Assembly for AP1 is a complete differential unit, sold as one assembly
Go Tuning lists this assembly for US 2000-2003 model year cars; US 2004-2005 cars with the F22C1 take the AP2 version
Spoon builds each assembly to order, with a factory lead time of about one month
Spoon does not list differential fluid among the contents; plan on fresh fluid at installation

Frequently Asked Questions

Why buy the LSD Differential Assembly for AP1 instead of the separate parts? Because the setup is done. Spoon fits its 4.44 final gear and LSD into a new Honda differential, then adjusts, balances and checks the whole unit before it ships. Buying the LSD Differential Assembly for AP1 removes the need to find a shop that can set gear mesh and preload correctly, and the original differential stays intact as a spare.
How does the 4.44 ratio change the feel of the car? Each gear is about 8 percent shorter than with the factory 4.10 final drive, so the car pulls harder in every ratio and reaches the top of each gear sooner. The flip side is higher engine speed at a steady highway cruise. On a track or a tight road the trade is easy to accept, while on long commutes it is noticeable.
Is the differential new or rebuilt? Spoon builds it from a new genuine Honda differential assembly, not a used core. The Spoon final gear and Spoon LSD are fitted inside, and the unit is washed, measured and assembled to Spoon specification. That gives a fresh housing and bearings alongside the upgraded internals, which matters on a car that may be two decades old.
Does it fit a 2004 or 2005 US S2000? No. Those cars carry the 2.2L F22C1, and Go Tuning, the sole US distributor for Spoon, assigns them to the AP2 version of this assembly. This AP1 unit is sold for 2000 to 2003 model year US cars, and Spoon registers it for JDM AP1 cars with the F20C built from 1999 to 2005.
How involved is installation? It is a lift job for a shop that works on rear-drive cars. The factory differential comes out with the axles and propeller shaft disconnected, and the Spoon unit goes in as a complete assembly weighing a listed 33 kg. Refill with fresh differential fluid of the grade the installer recommends for a limited-slip unit.

About Spoon Sports

Spoon Sports was founded in 1988 in Suginami, Tokyo, by Tatsuru Ichishima, a former Honda race car tester and driver, with backing from Honda and Mugen. The company has raced Hondas from its first season, when Ichishima’s own Civic became the first Civic to enter the Japan Touring Car Championship, and its Type One workshop, opened in 2001, services and tunes the cars its parts are developed on. Spoon builds engine, drivetrain, exhaust, chassis and aero parts for Honda models and proves them on circuits and in endurance racing, including the 25 Hours of Thunderhill.
