Which Nissan models does this 300ZX NTR-R1 Coilover Kit fit?

This Nitron 300ZX NTR-R1 fits the Z32 Nissan 300ZX.

What does the Nitron NTR-R1 replace on the Z32 300ZX?

It replaces the factory springs and dampers at all four corners with Nitron NTR-R1 coilover units, adding adjustable damping, adjustable ride height, and firmer race springs. The rear keeps the OEM suspension type.

What kind of adjustment does the Nitron NTR-R1 offer?

Combined compression and rebound adjustment at each corner, with an internal reservoir so there is no remote reservoir to mount or route.

Are top plates included with the Nitron NTR-R1 kit?

Yes. The kit includes adjustable top plates for both the front and rear.

Can the ride height be adjusted on the Nitron NTR-R1?

Yes. The Nitron NTR-R1 has adjustable spring perches for independent ride height setting at each corner.

Can I get custom spring rates for my setup?

Yes. Every kit is hand assembled to order, and custom spring rates outside the standard range are available by contacting us directly.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Nitron NTR-R1 Coilover Kit for Z32 Nissan 300ZX

The Nitron 300ZX NTR-R1 Coilover Kit is for the Z32 that has outlived its original dampers and needs its body control back. A heavy 1990s grand tourer leans, dives, and floats over bumps once the factory dampers and springs have worn, and the car’s handling suffers well before the engine does. Nitron’s passive NTR-R1 replaces the spring and damper at each corner with a coilover, pairing firmer race springs with a damper built to control them, and it adds adjustable spring perches for setting ride height. Adjustable top plates come included for both the front and rear, so the alignment can be set properly once the ride height changes. The rear keeps the OEM suspension type. The result is a Z32 that turns in more cleanly, stays flatter through corners, and settles quickly after a bump, whether it’s a road car that sees spirited driving or one that goes to autocross and track days.

Unique Technology

Each Nitron NTR-R1 damper is a monotube design pressurized with nitrogen gas, which keeps the oil from aerating and holds damping consistent as the dampers heat up over a long session. The valving comes from motorsport work and is tuned to the weight and spring rates of a Z32 300ZX instead of being adapted from a generic curve. Compression and rebound are adjusted together through a single 2-way adjustment at each corner, and the reservoir is internal, so there is nothing remote to mount or route.
- Basic Damper Design:
  1. End Eye / Top Mount
  2. Damper Piston & Shim Stack
  3. Shaft / Rod
  4. Floating / Separator Piston
  5. Suspension Oil
  6. Compressed Nitrogen Gas

Bespoke Engineering

Every Nitron 300ZX NTR-R1 Coilover Kit is hand assembled to order in the UK. Spring rates and valving are matched to how the car will really be used, whether that’s a street car or a dedicated track build, and custom spring rates are available for owners who want to shift the balance of the car one way or the other.

Features

OEM rear suspension type
Internal reservoir type
2-way combined adjustment
Full alloy body
Preload adjuster
Combined 24 clicks of adjustment
Nitrogen gas charged
Precision bearing spacers supplied as required
Consists of 4 coilovers, and top mounts
Hand made to order

Specifications

Coilover Type: NTR-R1
Adjustment Type: 2-way combined
Adjustment: 24 clicks combined
Rear Suspension Types: OEM
Droplinks Included: No

Applications

Nissan 300ZX: Z32 | 1990-1996

Other Suspension Kits for Z32 Nissan 300ZX

NTR-R3 Coilover Kit

Notes

Custom spring rates also available, please contact us directly here for more information or for a consultation on custom rates
Images used for illustration purposes only. Specific details, finishes and end fittings may differ from that shown.
Precision bearing spacers supplied as required

Frequently Asked Questions

Which Nissan models does this 300ZX NTR-R1 Coilover Kit fit? This Nitron 300ZX NTR-R1 fits the Z32 Nissan 300ZX.
What does the Nitron NTR-R1 replace on the Z32 300ZX? It replaces the factory springs and dampers at all four corners with Nitron NTR-R1 coilover units, adding adjustable damping, adjustable ride height, and firmer race springs. The rear keeps the OEM suspension type.
What kind of adjustment does the Nitron NTR-R1 offer? Combined compression and rebound adjustment at each corner, with an internal reservoir so there is no remote reservoir to mount or route.
Are top plates included with the Nitron NTR-R1 kit? Yes. The kit includes adjustable top plates for both the front and rear.
Can the ride height be adjusted on the Nitron NTR-R1? Yes. The Nitron NTR-R1 has adjustable spring perches for independent ride height setting at each corner.
Can I get custom spring rates for my setup? Yes. Every kit is hand assembled to order, and custom spring rates outside the standard range are available by contacting us directly.

About Nitron Suspension

Nitron Suspension has been at the forefront of precision suspension engineering since 1998, founded by Guy Evans with the goal of building high-performance shocks for enthusiasts and professionals alike. Over 200 dealers now carry Nitron products across Europe, Asia, the US, Australasia, and Africa. In 2008, the company moved into a dedicated facility in the UK’s Motorsport Valley, adding dynamometers, 5-axis CNC machines, and 3D CAD capabilities to support both growing demand and continued product development. A second expansion came in 2023 with a new office in Murrieta, California. The team behind every Nitron product draws from deep backgrounds in machining, materials technology, hydraulics, bike engineering, and F1 racing, with many engineers bringing firsthand experience as competitive drivers and riders. That depth of knowledge across both the technical and competitive sides of motorsport shapes every product Nitron develops.
