Which Porsche 911 models do the Moton 2-Way Clubsport Coilovers for 996 AWD fit?

MOTON lists the Moton 2-Way Clubsport Coilovers for 996 AWD for the Porsche 911 Carrera 4 / Carrera 4S / Turbo (996, 1997 to 2005). Each Clubsport set is built to order in the Netherlands for that fitment, so confirm the exact model, year and any previous suspension changes with us before ordering.

How does the 2-Way Clubsport kit compare with the other MOTON kits for the 996 Turbo or Carrera 4?

The 2-Way Clubsport adjusts rebound on the damper and compression on a remote reservoir, so the two can be tuned independently on the 996 Turbo or Carrera 4. Against the 3-Way Motorsport it keeps compression as one circuit rather than two, which makes it quicker to set up. It is the kit for a 996 Turbo or Carrera 4 that tracks regularly.

Where do the included droplinks go on a 996 Turbo?

On the Turbo, MOTON lists the included droplinks for the rear and offers a front pair, DLA-10-233-251, separately. The supplied pair is DLA-10-188-206, adjustable from 188 mm to 206 mm on M10 threads. Ask us to confirm positions for a Carrera 4 or 4S before installation.

What comes in the box?

Four non-inverted monotube coilovers with springs, each with a rebound adjuster and a reservoir-mounted compression adjuster, pillowball front camber plates, and a pair of adjustable aluminum droplinks with M10 threads, built to order for the 996 Turbo or Carrera 4. Wheel spacers, any electronic damper cancellation and the alignment are not included, and the kit ships without spring preload set.

What do the remote reservoirs do on the 996 Turbo or Carrera 4 kit?

Each damper in the 996 Turbo or Carrera 4 kit is connected by hose to an external reservoir that holds extra oil and the gas charge and carries the compression adjuster. The added volume helps the damper stay consistent as it heats up over a long session, and it puts the adjuster where it is easy to reach.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Moton 2-Way Clubsport Coilovers for 996 AWD Porsche 911 Turbo, Carrera 4 and 4S

Moton’s 2-Way Clubsport Coilovers for 996 AWD Porsche 911 Turbo, Carrera 4 and 4S bring two-way damping to the 996 Turbo, Carrera 4 and 4S: rebound on the damper body and compression on a reservoir connected by hose. The all-wheel-drive 996 range runs from the narrow-body Carrera 4 to the wide-body Carrera 4S and the twin-turbocharged 3.6-litre Turbo, and MOTON lists one set for all three.

Design and Performance

Separating compression from rebound changes how the 996 Turbo or Carrera 4 takes a kerb without changing how it recovers. Separate high-speed and low-speed compression is the job of the Moton 3-Way Motorsport Coilovers, the race kit for the 996 Turbo or Carrera 4.

Features

Non-inverted monotube dampers, adjustable for rebound and compression
Compression adjuster on an external remote reservoir
Threaded ride height at all four corners
True coilover layout front and rear
Pillowball front camber plates
Elevated top guide with helper piston
Quick-disconnect couplings, front and rear
Adjustable aluminum droplinks, DLA-10-188-206, M10, 188 mm to 206 mm
Fully rebuildable, 24-month AST x MOTON warranty

What’s Included

Front coilovers with remote reservoirs (L/R)
Rear coilovers with remote reservoirs (L/R)
Front and rear springs
Pillowball front camber plates (L/R)
Adjustable droplinks (x2)

Applications

Porsche 911 Carrera 4 / Carrera 4S / Turbo: 996 | 1997-2005

Notes

The Moton 2-Way Clubsport Coilovers for 996 AWD fit the all-wheel-drive Carrera 4, 4S and Turbo; the rear-drive Carrera 2 takes the Moton 2-Way Clubsport Coilovers for 996 C2 Porsche 911 Carrera
Route reservoir hoses clear of moving parts and secure them at the banjo
Keep at least 5 mm between wheel and damper; some factory wheels need a spacer
Kits are built to order in the Netherlands; lead time is confirmed at order
Images show representative MOTON kits

Frequently Asked Questions

Which Porsche 911 models do the Moton 2-Way Clubsport Coilovers for 996 AWD fit? MOTON lists the Moton 2-Way Clubsport Coilovers for 996 AWD for the Porsche 911 Carrera 4 / Carrera 4S / Turbo (996, 1997 to 2005). Each Clubsport set is built to order in the Netherlands for that fitment, so confirm the exact model, year and any previous suspension changes with us before ordering.
How does the 2-Way Clubsport kit compare with the other MOTON kits for the 996 Turbo or Carrera 4? The 2-Way Clubsport adjusts rebound on the damper and compression on a remote reservoir, so the two can be tuned independently on the 996 Turbo or Carrera 4. Against the 3-Way Motorsport it keeps compression as one circuit rather than two, which makes it quicker to set up. It is the kit for a 996 Turbo or Carrera 4 that tracks regularly.
Where do the included droplinks go on a 996 Turbo? On the Turbo, MOTON lists the included droplinks for the rear and offers a front pair, DLA-10-233-251, separately. The supplied pair is DLA-10-188-206, adjustable from 188 mm to 206 mm on M10 threads. Ask us to confirm positions for a Carrera 4 or 4S before installation.
What comes in the box? Four non-inverted monotube coilovers with springs, each with a rebound adjuster and a reservoir-mounted compression adjuster, pillowball front camber plates, and a pair of adjustable aluminum droplinks with M10 threads, built to order for the 996 Turbo or Carrera 4. Wheel spacers, any electronic damper cancellation and the alignment are not included, and the kit ships without spring preload set.
What do the remote reservoirs do on the 996 Turbo or Carrera 4 kit? Each damper in the 996 Turbo or Carrera 4 kit is connected by hose to an external reservoir that holds extra oil and the gas charge and carries the compression adjuster. The added volume helps the damper stay consistent as it heats up over a long session, and it puts the adjuster where it is easy to reach.

About Moton

MOTON Suspension Technology was founded in the Netherlands in 1999, and by June 2000 around 30 percent of the cars at the 24 Hours of Le Mans ran its dampers. MOTON has since won in the FIA GT and FIA Sportscar championships, the ETCC and WTCC, Grand-Am and World Challenge. AST Suspension acquired the brand in 2011, and every MOTON damper is now developed, tested and built by the AST x MOTON team in the Netherlands, part of the Roosen Industries group since 2016.
