What rear brakes come in the MONO4 TA and MONO4r TA Big Brake Kit for BNR34?

Two Racing MONO4r TA calipers, the rear-only four-piston pipeless caliper Endless lists for the R34, on 332mm x 30mm three-piece E-slit rotors with RCP197 pads. Endless pairs them with the MONO4 TA front calipers included in this Big Brake Kit for BNR34.

Does the Racing MONO4r TA rear set for the BNR34 GT-R save money over separate kits?

Yes. Endless prices the set below the MONO4 TA front kit and the MONO4r TA rear kit added together, and it arrives as one order with matched brackets and lines, so the whole car is converted to TA calipers in a single job.

Does the parking brake still work on the Racing MONO4r TA rear set for the BNR34 GT-R?

The factory parking brake stays. Endless three-piece rear rotors retain it, and this kit runs 332mm x 30mm three-piece rotors at the rear, so the BNR34 GT-R keeps a working parking brake after the upgrade. Endless two-piece rear rotors are the ones that do not retain it.

Is a six-piston rear available instead?

Yes. Endless also lists the six-piston Racing MONO6r TA rear for the BNR34, on 355mm rotors, which pairs with its MONO6 TA front kits. That route is heavier and costs more; this four-piston set is the lighter TA option of the two for the R34.

How should the Racing MONO4r TA rear set for the BNR34 GT-R be bedded in?

Endless specifies raising the rotors to around 400 to 500 degrees C without hard stops, then letting them cool naturally to below 100 degrees C. Do it on a dry day, as Endless notes that bedding in the rain can keep the pads from full performance.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Endless Racing MONO4 TA / Racing MONO4r TA Front and Rear Big Brake Kit for BNR34 Nissan Skyline GT-R with 332mm Rear Rotors

Endless’s Racing MONO4 TA / Racing MONO4r TA Front and Rear Big Brake Kit for BNR34 Nissan Skyline GT-R gives the rear of the R34 the pipeless MONO4r TA, the rear-only TA caliper Endless pairs with its MONO4 TA front. The rear body is a 2,100g forged monobloc with stainless pistons and a 3D-cut surface, clamping 332mm x 30mm three-piece E-slit rotors on Tufram-coated bells with the RCP197 pad. Buying the set covers both axles in one order with matched hardware.

Features

Racing MONO4r TA forged monobloc rear caliper, 2,100g
332mm x 30mm three-piece E-slit rear rotors
RCP197 rear pad shape
Racing MONO4 TA front calipers on 355mm rotors
Pipeless construction at all four corners
Tufram-coated bells

Specifications

Front caliper: Endless Racing MONO4 TA, four-piston forged monobloc, pipeless
Front caliper weight: 2,100g (Endless USA; Endless Japan lists 2,256g)
Front rotors: 355mm x 32mm, two-piece
Rear caliper: Endless Racing MONO4r TA, four-piston forged monobloc, pipeless
Rear caliper weight: 2,100g
Rear rotors: 332mm x 30mm, three-piece
Pad shapes: RCP146 front, RCP197 rear
Minimum wheel size: 15 inch front, per Endless

What’s Included

Endless Racing MONO4 TA front calipers (2)
Endless Racing MONO4r TA rear calipers (2)
Front and rear Endless brake pad sets
Caliper mounting brackets, front and rear
Front rotors (2), 355mm x 32mm two-piece
Rear rotors (2), 332mm x 30mm three-piece
Brake lines (4)

Applications

Nissan Skyline GT-R: BNR34 | 1999-2000 (production to September 2000)

Notes

Front and rear set. Same parts as the listing that leads with the 355mm front rotors
Endless lists this kit for BNR34 cars built up to September 2000 and excludes later-production cars
The three-piece rear rotors in this Big Brake Kit for BNR34 retain the factory parking brake
Replace E-slit rotors when the E marks on the face have worn away
Endless gives 15 inch as the minimum wheel for both calipers
Made to order in Japan; bleed with DOT4 or higher fluid

Frequently Asked Questions

What rear brakes come in the MONO4 TA and MONO4r TA Big Brake Kit for BNR34? Two Racing MONO4r TA calipers, the rear-only four-piston pipeless caliper Endless lists for the R34, on 332mm x 30mm three-piece E-slit rotors with RCP197 pads. Endless pairs them with the MONO4 TA front calipers included in this Big Brake Kit for BNR34.
Does the Racing MONO4r TA rear set for the BNR34 GT-R save money over separate kits? Yes. Endless prices the set below the MONO4 TA front kit and the MONO4r TA rear kit added together, and it arrives as one order with matched brackets and lines, so the whole car is converted to TA calipers in a single job.
Does the parking brake still work on the Racing MONO4r TA rear set for the BNR34 GT-R? The factory parking brake stays. Endless three-piece rear rotors retain it, and this kit runs 332mm x 30mm three-piece rotors at the rear, so the BNR34 GT-R keeps a working parking brake after the upgrade. Endless two-piece rear rotors are the ones that do not retain it.
Is a six-piston rear available instead? Yes. Endless also lists the six-piston Racing MONO6r TA rear for the BNR34, on 355mm rotors, which pairs with its MONO6 TA front kits. That route is heavier and costs more; this four-piston set is the lighter TA option of the two for the R34.
How should the Racing MONO4r TA rear set for the BNR34 GT-R be bedded in? Endless specifies raising the rotors to around 400 to 500 degrees C without hard stops, then letting them cool naturally to below 100 degrees C. Do it on a dry day, as Endless notes that bedding in the rain can keep the pads from full performance.

About Endless

Endless was founded in 1986, when Isao Hanazato began developing brake pads out of his own racing experience, and the company builds its friction material, rotors, calipers and brake fluid in Saku City, Nagano. It has run its own team since 1991, in the All Japan F3 Championship and the Mirage Cup, and by 2017 had supplied brake fluid to Formula 1 for fifteen consecutive years. The pads supplied in each kit are Endless compounds, so caliper and friction material come from the same company.
