HKS S-Type Oil Cooler Kit for ZN6 / ZC6 Toyota 86 & Subaru BRZ

HKS S-Type Oil Cooler Kit for ZN6 / ZC6 Toyota 86 & Subaru BRZ

Two types of kits are available with R Type kits : filter relocation type and S Type : sandwich type which is held at the oil filter.

Oil Temperature Controlled by Thermostat

HKS Oil Coolers use high performance cooling cores; so there is the possibility of overcooling which is prevented by the use of a thermostat (some vehicles excluded). This thermostat has high response and able to react quickly to change of oil temperature. Once oil temperature reaches the set level, the oil will flow through the cooler core but bypasses when temperatures drop lower. This allows engine oil to be maintained at the ideal temperature.

• Thermostat Opening Temperature 70 (±3)
• Thermostat Full Open Temperature 80 (±3)

Thermostat Relief Feature Allows for Safe Operation in Times of Emergency

• In cases where the core or lines become blocked and the oil pressure rises, the thermostat will bypass the core to maintain the correct oil pressure and prevent damage to the oil lines and fittings.

Stainless Braided Hoses Chosen for Increasing Durability

• Hose lengths and fitting types are tailored to each vehicle application to ensure easy and tidy fitting while preventing connection errors.

S-Type Oil Cooler Kit

HKS Oil Cooler S Type includes a built-in thermostat attachment, and which is held in place by the oil filter. Also, it provides superior cost performance.

Features

Newly designed single tube type fitting. Engine dyno tests and experience from D1 racing found that the oil pressure of the FA20 engine is extremely high compared to most conventional mass-produced engines (max oil pressure : over 12kgf / cm2). New single tube fitting withstanding the high oil pressure was designed and included in this kit.

Installing the core to the inner side of the fender enables a vehicle tuned with GT Supercharger to install a front mount type intercooler kit. Also, a special air guide is included to provide higher cooling performance; this kit is also recommended for NA vehicles who enjoy circuit driving.

Special spacer and center bolt are included so the kit parts do not come in contact with the brim on the oil filter installation position when installing the oil cooler attachment.

What’s Included

• Oil Cooler Core
• S-type Attachment
• Spacer
• Center Bolt
• Banjo
• Banjo Bolt
• Bracket
• Air guide
• Oil Cooler Hose
• Accessory Parts
