Do the GiroDisc Dimpled Slotted Rear Rotors for W463 match the dimpled front set?

Yes. The GiroDisc Dimpled Slotted Rear Rotors for W463 share the dimpled and slotted face of the A1-260DS front rotors, so a G63 fitted with both carries the same surface at all four corners. Front and rear are sold as separate pairs, and each pair has its own replacement ring part number.

Are the rear calipers or brake lines changed during installation?

No. GiroDisc lists this rotor as a direct replacement for the factory disc. It bolts to the hub, the original rear calipers refit as they were and the brake lines are untouched, so the bias and ABS calibration set by Mercedes-AMG stay exactly as delivered.

What do the curved vanes in the dimpled G63 rear rotor do?

The curved vanes inside the ring are shaped like the blades of a centrifugal pump. As the rotor turns they draw air in near the hub and push it out through the rim, moving heat out of the disc. Because the vanes are directional, each rotor is made for one side of the vehicle.

When should the dimpled rear rings be replaced?

Replace them when they reach the minimum thickness marked on the hat and on the edge of the ring, or sooner if a crack runs out to the ring edge. The replacement part is the D2-260DS ring pair, which comes with new hardware and bolts to the existing GiroDisc hats.

Where are the GiroDisc G63 rings made?

GiroDisc pours its proprietary high-carbon iron in the USA and machines every ring start to finish at its own facility in Bellingham, Washington. The hats are machined from US-sourced 6061-T6 aluminum, and the drive pins are also produced by GiroDisc to its own specification.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

GiroDisc Dimpled Slotted Rear Rotors for W463 Mercedes-AMG G63

GiroDisc’s Dimpled Slotted Rear Rotors for W463 Mercedes-AMG G63 give the rear of the G63 the same dimpled and slotted face as GiroDisc’s matching front set, so all four corners match. Each assembly floats a GiroDisc cast iron ring on a hat of US-sourced 6061-T6 aluminum, held by ten alloy steel drive pins that GiroDisc makes itself. The fit is direct: the rotor bolts to the hub, the factory calipers return unchanged and nothing on the vehicle is altered.

Construction

GiroDisc machines the ring from start to finish in Bellingham, Washington, after it is poured in the USA from the company’s proprietary iron. Curved vanes inside the GiroDisc Dimpled Slotted Rear Rotors for W463 work as a centrifugal pump, drawing air in at the hub and pushing it out through the rim. Class 12.9 cap screws with hardened washers secure the cadmium-plated drive pins.

Features

Dimpled and slotted face to match the A1-260DS front rotors
Bolts on with the factory rear calipers
Ten GiroDisc drive pins, cadmium plated for corrosion resistance
Anti-noise spring washers that stop cold rattle
Curved centrifugal vanes
Ring poured in the USA and machined in Bellingham, Washington

What’s Included

Rear rotor assemblies (L/R)

Applications

Mercedes-AMG G63: W463

Notes

When the iron is worn, fit the GiroDisc G63 dimpled and slotted rear replacement rings to these hats
The front axle partner is the GiroDisc G63 dimpled slotted front rotors
Rotors are left and right handed and labeled for position
Stock photography may not depict the actual product

Frequently Asked Questions

Do the GiroDisc Dimpled Slotted Rear Rotors for W463 match the dimpled front set? Yes. The GiroDisc Dimpled Slotted Rear Rotors for W463 share the dimpled and slotted face of the A1-260DS front rotors, so a G63 fitted with both carries the same surface at all four corners. Front and rear are sold as separate pairs, and each pair has its own replacement ring part number.
Are the rear calipers or brake lines changed during installation? No. GiroDisc lists this rotor as a direct replacement for the factory disc. It bolts to the hub, the original rear calipers refit as they were and the brake lines are untouched, so the bias and ABS calibration set by Mercedes-AMG stay exactly as delivered.
What do the curved vanes in the dimpled G63 rear rotor do? The curved vanes inside the ring are shaped like the blades of a centrifugal pump. As the rotor turns they draw air in near the hub and push it out through the rim, moving heat out of the disc. Because the vanes are directional, each rotor is made for one side of the vehicle.
When should the dimpled rear rings be replaced? Replace them when they reach the minimum thickness marked on the hat and on the edge of the ring, or sooner if a crack runs out to the ring edge. The replacement part is the D2-260DS ring pair, which comes with new hardware and bolts to the existing GiroDisc hats.
Where are the GiroDisc G63 rings made? GiroDisc pours its proprietary high-carbon iron in the USA and machines every ring start to finish at its own facility in Bellingham, Washington. The hats are machined from US-sourced 6061-T6 aluminum, and the drive pins are also produced by GiroDisc to its own specification.

About GiroDisc

GiroDisc designs, manufactures, and sells 2-piece, fully floating brake rotors for a wide range of performance vehicles. Every major component, including the hats, rotor rings, and drive pins, is manufactured in-house at their facility in Bellingham, Washington, from domestically sourced materials. GiroDisc rotors use a proprietary high-carbon iron ring formulated for superior metallurgy and thermal performance, paired with reusable machined-aluminum hats that reduce the long-term cost of maintaining a high-performance brake system. The 2-piece floating design sheds unsprung and rotating mass while remaining street-friendly, delivering race-proven braking for track and street use alike.
