Will the Fabspeed RSR Header Muffler Kit fit my Porsche 911 Carrera 3.0 or 3.2?

Yes. The Fabspeed RSR Header Muffler Kit is built for all 1976-1989 Porsche 911 Carrera models, with separate heat exchanger configurations for the 1976-1983 3.0L cars and the 1984-1989 3.2L cars. Select the one matching your engine at checkout, along with your Sport Cat and tip preferences.

How much power does it add, and where in the rev range?

Fabspeed's DynoJet testing recorded 18 whp and 17 ft-lbs of torque at 3900 rpm, the largest gain anywhere on the curve, and 12 whp and 11 ft-lbs at peak horsepower. The kit is tuned to build midrange rather than chase a headline peak number, which is where a road-driven 3.0 or 3.2 actually lives.

What is the difference between the With Heat and Without Heat configurations?

With Heat retains the heat exchangers that feed the car's cabin heating and defrost. Without Heat omits them entirely for a lighter, simpler system, which suits a dedicated track or fair-weather car but leaves you with no heat and no windscreen defrost. Choose With Heat for anything that sees real road use.

Should I add Sport Cats?

Sport Cats are the option to take if the car is road driven, since they keep a catalyst in the system while flowing far better than the factory unit. Cars used exclusively on track often take the no Sport Cat configuration. Sport Cats can also be purchased separately later if you want to stage the build.

What comes in the box?

The kit ships with the RSR long-tube headers and merge collectors, the Maxflo muffler, and all required hardware and gaskets. Whatever you select at checkout comes with it: heat exchangers, Sport Cats, your chosen tip style, and the optional muffler bypass pipes or factory-style oil line upgrade kit for 3.2L cars.

How difficult is the install, and why the torque note?

Fabspeed builds it as a bolt-on with no cutting or welding, but it is header work, so plan for proper engine access and a lift. The bumper needs slight modification for the dual outlets. After the first heat cycle, retorque every exhaust bolt to OEM spec; headers shift as they reach temperature and the seal will not hold without it.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Fabspeed RSR Header Muffler Kit for Porsche 911 Carrera

The Fabspeed RSR Header Muffler Kit for Porsche 911 Carrera 3.0 & 3.2 is the point where an exhaust upgrade stops being an exhaust upgrade and becomes an engine decision. Fabspeed designs, engineers, dyno tests and race proves its own work from its Fort Washington, Pennsylvania facility, and the RSR kit is the full expression of that: equal length long-tube primaries running into F1 style high velocity 3-into-1 pyramidal investment cast merge collectors, feeding straight through to a Maxflo muffler and out a pair of tips. On a DynoJet it returned 18 whp and 17 ft-lbs at 3900 rpm across the curve and 12 whp and 11 ft-lbs at peak horsepower, while taking 23 pounds off the back of the car. It is loud, it is unmistakably a CUP car, and it is configured to order with or without heat exchangers, with or without Sport Cats, and with the tip style you want.

Features

Loud and aggressive CUP car sound through dual outlets
Free-flowing headers feeding directly into the Maxflo muffler
Lightweight
Configured to order with or without heat exchangers, with or without Sport Cats, and with a choice of tip style
Optional muffler bypass pipes for maximum weight savings, more aggressive sound and increased peak horsepower
Optional factory-style oil line upgrade kit for 3.2L cars
Simple DIY bolt-on installation, no cutting or welding required
Backed by the Fabspeed lifetime warranty

Specifications

Material: T304 stainless steel
Tubing: 14-16 gauge, C.N.C. mandrel bent
Headers: RSR long-tube, equal length primaries
Collectors: F1 style high velocity 3-into-1 pyramidal investment cast merge
Peak curve gain: 18 whp and 17 ft-lbs at 3900 rpm
Gain at peak horsepower: 12 whp and 11 ft-lbs
Weight savings: 23 lbs (depending on exhaust and tip option)
Outlet: dual

What’s Included

RSR long-tube headers with merge collectors
Maxflo muffler
All required hardware and gaskets
Heat exchangers, Sport Cats, tip style, muffler bypass pipes and the OEM oil line kit as selected at checkout

Applications

Porsche 911 Carrera 3.0: 1976-1983 | 3.0L H6
Porsche 911 Carrera 3.2: 1984-1989 | 3.2L H6

Notes

The dual outlets require slight modification to the factory rear bumper for proper fitment
To ensure a proper header seal, torque all exhaust bolts to the OEM specification after the initial heat cycle
The Without Heat configuration runs no heat exchangers, so the car has no cabin heat or defrost; choose a With Heat option if it sees road use in cold weather
Sport Cats can be added to this kit at checkout, or fitted separately with the Fabspeed Sport Cat for Porsche 911 Carrera 3.0 & 3.2 (FS.POR.911.SC)
Muffler bypass pipes are offered as an option on this kit for the loudest, lightest configuration; the Fabspeed Muffler Bypass Pipe (FS.POR.911.MB) is also sold on its own
If you are not replacing the headers, the catback-only alternatives are the Fabspeed Maxflo Performance Exhaust System and the Fabspeed Supercup Exhaust System
All Fabspeed products are expected to ship within one week of order, though timelines are often much quicker

Frequently Asked Questions

Will the Fabspeed RSR Header Muffler Kit fit my Porsche 911 Carrera 3.0 or 3.2? Yes. The Fabspeed RSR Header Muffler Kit is built for all 1976-1989 Porsche 911 Carrera models, with separate heat exchanger configurations for the 1976-1983 3.0L cars and the 1984-1989 3.2L cars. Select the one matching your engine at checkout, along with your Sport Cat and tip preferences.
How much power does it add, and where in the rev range? Fabspeed’s DynoJet testing recorded 18 whp and 17 ft-lbs of torque at 3900 rpm, the largest gain anywhere on the curve, and 12 whp and 11 ft-lbs at peak horsepower. The kit is tuned to build midrange rather than chase a headline peak number, which is where a road-driven 3.0 or 3.2 actually lives.
What is the difference between the With Heat and Without Heat configurations? With Heat retains the heat exchangers that feed the car’s cabin heating and defrost. Without Heat omits them entirely for a lighter, simpler system, which suits a dedicated track or fair-weather car but leaves you with no heat and no windscreen defrost. Choose With Heat for anything that sees real road use.
Should I add Sport Cats? Sport Cats are the option to take if the car is road driven, since they keep a catalyst in the system while flowing far better than the factory unit. Cars used exclusively on track often take the no Sport Cat configuration. Sport Cats can also be purchased separately later if you want to stage the build.
What comes in the box? The kit ships with the RSR long-tube headers and merge collectors, the Maxflo muffler, and all required hardware and gaskets. Whatever you select at checkout comes with it: heat exchangers, Sport Cats, your chosen tip style, and the optional muffler bypass pipes or factory-style oil line upgrade kit for 3.2L cars.
How difficult is the install, and why the torque note? Fabspeed builds it as a bolt-on with no cutting or welding, but it is header work, so plan for proper engine access and a lift. The bumper needs slight modification for the dual outlets. After the first heat cycle, retorque every exhaust bolt to OEM spec; headers shift as they reach temperature and the seal will not hold without it.

About Fabspeed

Fabspeed Motorsport works out of a 26,000 square foot facility in Fort Washington, Pennsylvania, where design, engineering, dyno testing, street testing and race development all happen under one roof. The shop is a fixture for the Porsche Club of America, Ferrari, McLaren and Lamborghini crowds, and collaborates with race engine builders and tuners in Italy, Germany and the United States. Systems are fabricated from aerospace-grade austenitic stainless steel, titanium and carbon fiber, and every Fabspeed performance product is backed by the Fabspeed lifetime warranty.
