What does the Dinan M340i Axle-Back Exhaust fit?

The Dinan M340i Axle-Back Exhaust fits the G20 BMW M340i and G22, G23, and G26 M440i (2020-2024) with the B58 turbocharged inline-six. It bolts to the factory mounting points, replacing the rear section of the exhaust for a louder, fuller note.

What finish are the tips?

This version uses polished stainless clamp-on tips. The system is 100% T304 stainless steel, TIG-welded and brush-finished for a clean, corrosion-resistant appearance at the rear of the car.

An axle-back exhaust is chosen mainly for sound and styling. The Dinan M340i Axle-Back Exhaust reduces backpressure, which can free up a small amount of power, but the primary benefit is the improved note and appearance.

Is installation difficult?

No. The Dinan M340i Axle-Back Exhaust is a bolt-on installation using the factory mounting points, with no cutting or welding required. Mounting hardware is included to complete the swap.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Dinan Free Flow Axle-Back Exhaust with Polished Tips for G20 BMW M340i and G22 / G23 / G26 M440i

The Dinan M340i Axle-Back Exhaust is a T304 stainless steel free-flow axle-back exhaust for the G20 BMW M340i and G22, G23, and G26 M440i and their B58 turbocharged inline-six. The free-flow rear section reduces backpressure for a louder, fuller note than the muted factory setup, capped with polished stainless clamp-on tips. TIG-welded and brush-finished throughout. Finished with polished stainless tips.

Features

Stock exhaust valve actuator reused and another valve/actuator added to the opposing side promoting even flow regardless of valve position
Computer controlled exhaust valves are retained and limit noise during low speed driving and open fully during high-load conditions
Twin exhaust valves are a whopping 76mm diameter, making them 30% less restrictive than the OE valves
Quad 4″ diameter clamp-on, double-walled, polished and laser engraved exhaust tips
Easy bolt-on installation with included mounting hardware
Larger diameter piping for increased flow (76mm vs 70mm)
More Power: + 6hp @ 6600 RPM, + 5ft/lbs @ 6600 RPM
100% 304 stainless steel construction
4 lbs lighter than the stock system
Enjoyably louder, sportier sound

Specifications

Material: T304 stainless steel
Construction: TIG-welded, brush-finished
Design: free-flow axle-back
Exhaust tips: polished stainless, clamp-on
Fitment: direct bolt-on to factory mounting points

Applications

BMW M340i: G20 | 2020-2024 | 3.0L Turbo I6 B58
BMW M440i: G22 / G23 / G26 | 2021-2024 | 3.0L Turbo I6 B58

Notes

A black-tip version is available as Dinan part number D660-0085-BLK

Frequently Asked Questions

What does the Dinan M340i Axle-Back Exhaust fit? The Dinan M340i Axle-Back Exhaust fits the G20 BMW M340i and G22, G23, and G26 M440i (2020-2024) with the B58 turbocharged inline-six. It bolts to the factory mounting points, replacing the rear section of the exhaust for a louder, fuller note.
How much louder is it? The Dinan M340i Axle-Back Exhaust uses a free-flow design that reduces backpressure for a louder, fuller note than the muted factory system, while staying civil during normal cruising.
What finish are the tips? This version uses polished stainless clamp-on tips. The system is 100% T304 stainless steel, TIG-welded and brush-finished for a clean, corrosion-resistant appearance at the rear of the car.
Does it add power? An axle-back exhaust is chosen mainly for sound and styling. The Dinan M340i Axle-Back Exhaust reduces backpressure, which can free up a small amount of power, but the primary benefit is the improved note and appearance.
Is installation difficult? No. The Dinan M340i Axle-Back Exhaust is a bolt-on installation using the factory mounting points, with no cutting or welding required. Mounting hardware is included to complete the swap.

About Dinan

Founded in 1979, Dinan is North America’s leading BMW tuner, developing, manufacturing, and marketing a full line of high-performance products for BMW, MINI, and Mercedes-Benz. Dinan works through a nationwide network of Authorized Dinan Performance Centers, including select BMW dealerships and independent BMW service and performance shops. The company’s warranty program, introduced in 1996 with BMW of North America’s cooperation, matches BMW’s new car warranty and covers Dinan enhancements and the vehicle itself for up to 4 years or 50,000 miles. That coverage lets BMW owners add real performance without risking their factory warranty. Automotive publications have tested Dinan-enhanced BMWs against some of the world’s most exotic sports cars for three decades, and the results consistently hold up. Despite that performance, Dinan BMWs keep the reliability and everyday civility BMW owners expect. The product line spans engine, driveline, and chassis components across the full BMW lineup, covering acceleration, cornering, and stopping power. Every Authorized Dinan Performance Center can help build anything from a single upgrade to a complete Dinan BMW.
