Description

BBS FI-R Center Lock Gloss Platinum Wheel (20×9 +52) for 991 Porsche 911 GT3, Turbo and 911 R

The BBS FI-R Center Lock wheel in Gloss Platinum is the front corner BBS built for the broadest run of centerlock 991s, from the GT3 to the Turbo to the 911 R. BBS has built race wheels since the 1970s, and the FI-R uses the same multi-stage die-forging: a single billet of aluminum pressed into a monoblock whose grain structure follows the finished shape of the wheel rather than running straight through it. At 17.44lbs this is the lightest wheel in the Porsche FI-R program, and on a car that steers as precisely as a 991 GT3 the difference shows up the first time the wheel is turned. Gloss Platinum is the bright machined finish, which on a car this serious reads as a statement of what the wheel is rather than how it looks.

Forged Construction

BBS die-forges the FI-R under up to 18 million pounds of force, starting from a billet of 6000 series aluminum or the company’s own magnesium alloy depending on the application. Forging closes the porosity that casting leaves behind and aligns the grain along the load paths the wheel actually sees, so the rim section can be made thinner without giving up strength. The spokes, hub face and barrel are one continuous piece of metal, with no bolts, no welds and no joint to fatigue.

Weight and Design

Each cross spoke carries a relief hole that takes material out of a low-load area, and the back faces are milled to the minimum section the structure needs. 17.44lbs is a remarkable figure for a 20 inch wheel, and at the front axle it is felt more directly than anywhere else on the car: less gyroscopic resistance to a steering input, less rotating mass for the brakes to arrest, and less unsprung mass for the dampers to manage over a kerb.

Centerlock Fitment

This is a true centerlock wheel, machined for the single-nut hub Porsche fits to the GT cars and the Turbo rather than adapted from a five-lug pattern. The 84mm center bore locates on the factory centerlock spigot and the +52mm offset suits every application it is listed for. The rear it pairs with depends on the car: the GT3 and 911 R take the 20×12 +44, while the 991.2 Turbo takes the 20×11.5 +54.

Features

One-piece die-forged aluminum monoblock
Multi-stage die-forging for grain structure aligned to the wheel’s load paths
Weight relief milled into each cross spoke
Lightweight at 17.44lbs, the lightest in the Porsche FI-R program
Machined for the factory Porsche centerlock hub
Shared front fitment across the 991 GT3, Turbo and 911 R
Gloss Platinum finish
BBS Forged Line series

Specifications

Series – BBS Forged Line
Model – FI-R
Construction – One-piece die-forged aluminum monoblock
Diameter – 20″
Width – 9″
Offset – +52mm
Fitment – Porsche centerlock
Center Bore – 84mm
Weight – 17.44lbs (7.9kg)
Position – Front axle
Finish – Gloss Platinum
Part Number – FI133PG

Applications

Porsche 911 GT3: 991.1 | 2013-2016 | 3.8L Flat-Six
Porsche 911 GT3: 991.2 | 2017-2019 | 4.0L Flat-Six
Porsche 911 R: 991.1 | 2016 | 4.0L Flat-Six
Porsche 911 Turbo: 991.2 | 2017-2019 | 3.8L Twin-Turbo Flat-Six
Porsche 911 Turbo S: 991.2 | 2017-2019 | 3.8L Twin-Turbo Flat-Six

Notes

Sold as a single wheel, not a set of four
This is the front axle fitment, and the matching rear depends on the car
For the GT3 and 911 R the rear is the 20×12 +44, listed as the BBS FI-R Centerlock Wheel Set for the 991 GT3 and 911 R (FIR133/FIR134)
For the 991.2 Turbo the rear is the 20×11.5 +54, listed in Diamond Black, Matte Black and Diamond Silver (FI149)
The same front wheel is also listed in Matte Black (FI133MB)
Browse the full BBS FI-R centerlock range
Fits the factory Porsche centerlock hub only and will not mount to a standard 5-lug PCD hub
Centerlock installation calls for the correct Porsche centerlock socket and a torque wrench rated to the factory specification
TPMS sensors are not supplied with the wheel
Confirm caliper clearance before ordering if the vehicle runs an aftermarket brake kit
Vehicles that have been lowered or otherwise modified need sufficient clearance between the wheel arches and the suspension components. Tire size and positioning should both be checked against the revised setup.

Frequently Asked Questions

What does the BBS FI-R Center Lock wheel in 20×9 +52 fit? It is the front axle fitment for the 991.1 Porsche 911 GT3 from 2013 to 2016, the 991.2 GT3 from 2017 to 2019, the 2016 911 R, and the 991.2 911 Turbo and Turbo S from 2017 to 2019. All of those left the factory with centerlock hubs. It will not mount to a five-lug Porsche hub.
Why does one front wheel cover so many cars? Porsche used the same centerlock hub and the same front track across the GT and Turbo variants of the 991, so BBS only needed one front. The rears differ, because the GT3 and 911 R run a 20×12 +44 while the 991.2 Turbo runs a 20×11.5 +54. Confirm the rear against the specific car.
Is the FI-R forged or cast? Forged. BBS die-forges the FI-R from a single billet under up to 18 million pounds of force, producing a one-piece monoblock with no bolts or welds. Forging closes the internal porosity that casting leaves behind, which is what allows the rim section to be made thinner and lighter without giving up strength.
How much does the 20×9 FI-R weigh? 17.44lbs, or 7.9kg. That is the lightest wheel in the Porsche FI-R program and a low figure for any 20 inch wheel. At the front axle the saving is felt most directly, through steering response and through how little work the dampers have to do over a rough surface.
What is the center bore? 84mm, which locates on the Porsche centerlock hub spigot. Because the wheel is secured by a single central nut rather than five studs, no spacers, adapters or centering rings are used. The nut is torqued to the factory specification every time the wheel comes off, using the correct Porsche centerlock socket.
Will this clear carbon ceramic brakes? The 20×9 +52 is the BBS front fitment for cars delivered with the factory ceramic package, so clearance is accounted for in the design. Confirm before ordering if the car runs an aftermarket big brake kit, because caliper geometry varies between manufacturers and can change the clearance behind the spokes.

About BBS

In 1970, two race car enthusiasts from Schiltach in Germany, Heinrich Baumgartner and Klaus Brand, founded BBS to build lightweight fiberglass body panels that gave teams an advantage on track. BMW Motorsport noticed, and the company grew quickly. In 1983 BBS introduced the three-piece RS wheel, a design still regarded as one of the best ever made. The company remains committed to its founding idea: Technology through Motorsport.

BBS builds wheels for cars, trucks and SUVs across three ranges. The Forged Line covers one-piece and two-piece forged designs, the Performance Line covers one-piece and dual-construction flow formed models, and the Design Line covers low pressure cast rims. Design, testing and manufacturing all happen in house, which is how BBS keeps its original equipment programs and its motorsport programs feeding each other.
