APR Performance Carbon Fiber GTC-200 Adjustable Wing for Series 2 Lotus Elise

Adjustable wing for Series 2 Lotus Elise: the GTC-200 adjustable wing has been designed with an optimized 3D airfoil shape that enables it to span 59.5 inches and generate a significant amount of downforce. Due to this capability, it is considered a great option for compact and midsize sports and touring cars.

Downforce / Drag Graph

Downforce – |||
Drag – ||

Technical Features

The GTC Series airfoils are designed to deliver exceptional performance and precision. To achieve this, they are constructed using composite materials that merge carbon fiber reinforced polymer (CFRP), resulting in a sturdy but lightweight structure. The airfoils are further strengthened with pre-impregnated woven carbon fibers to enhance their durability. Advanced techniques such as pre-impregnated composite manufacturing, high-temperature autoclaving, vacuum bagging, and high-quality aluminum billet molds are utilized during production.
The GTC Series airfoils are made from composite materials, including carbon fiber reinforced polymer (CFRP), which is widely known for its lightweight and robust properties. These airfoils have a sophisticated design incorporating pre-impregnated carbon fibers to achieve an optimal balance of durability and lightness. The manufacturing process is designed to produce airfoils of superior quality, utilizing advanced techniques such as high-temperature autoclaving, pre-impregnated composite production, vacuum bagging, and top-quality aluminum billet molds. The result is a sturdy yet lightweight structure for the airfoils.
- By integrating carbon fiber composites onto 10mm 6061 billet aluminum pedestals and subjecting them to a matte black powder coating process, the GTC Series airfoils achieve improved stability, durability, and secure attachment. Using carbon fiber materials ensures that the airfoils remain lightweight and robust, enhancing their overall performance.

Applications

Lotus Elise: Series 2 | 2005-2011

Notes

The distance between the center of the mounting bases is 19 inches

Frequently Asked Questions

Which cars does this adjustable wing for Series 2 Lotus fit? This adjustable wing for Series 2 Lotus fits the 2005-2011 Series 2 Lotus Elise, as listed on the page. Confirm your model and model year with us before ordering.
Does it fit the Series 1, the Series 3 Elise or the Series 2 Exige? The page lists the Series 2 Elise for 2005-2011 only. The Series 2 Exige has its own listing, linked in the Notes, and the page does not list the Series 1 or the Series 3 Elise. Confirm with us before ordering if your car is one of those.
What is the mounting distance? The page says the distance between the centers of the mounting bases is 19 inches. It does not describe the mounting method further, so contact us if you want to go through the installation before ordering.
Does it come with Gurney flaps, and can the angle be adjusted? The page does not mention Gurney flaps or an angle-adjustment range for this model, although it is sold as an adjustable wing. Contact us if you need those details before ordering.
What is the wing made from, and how big is it? Carbon fiber reinforced polymer (CFRP) airfoils with pre-impregnated woven carbon fibers, made with pre-impregnated composite manufacturing, high-temperature autoclaving and vacuum bagging in aluminum billet molds. The span is 59.5 inches, on 10mm 6061 billet aluminum pedestals with a matte black powder coat.
What is the PPF film option, and how long does delivery take? PPF film is an optional extra for an additional $200, chosen at checkout. The wing is made to order or special order from the manufacturer, so we confirm the estimated lead time after you order. Talk to us first if you have a specific deadline.

About APR Performance

Since 1999, APR Performance has crafted aerodynamic performance components for the aftermarket automotive sector. Products are developed with computational fluid dynamics analysis and tested on track against performance specifications. APR’s proprietary manufacturing processes use pre-impregnated carbon fiber composites to make parts that are sturdy, light, and premium in quality.
