Does the Level 4 Supercharger Kit for E90 / E92 / E93 M3 include a tune?

Yes. Active Autowerke ships its MSS60 software with the Level 4 Supercharger Kit for E90, E92 and E93 M3 models, together with eight Bosch Motorsport injectors for the added fuel. The calibration is written for 93 or 91 octane pump fuel, and race fuel versions are available.

Should the S65 rod bearings be replaced before supercharging?

Yes. Active Autowerke recommends addressing the condition of the S65 rod bearings before any engine modification, and this kit adds 12 psi of boost. An E9X M3 with no record of bearing service should have them inspected or replaced before the supercharger goes on.

What separates the Level 2, Level 3 and Level 4 kits?

Level 2 runs a Rotrex C38-92 at 8 psi without water/methanol injection. Level 3 keeps the C38-92 and adds water/methanol injection with an upgraded pulley for 9 psi. Level 4 moves to the C38-92R at 12 psi with injection, the upgraded pulley and custom software.

Does the kit use an intercooler?

Yes. A front-mount air-to-air intercooler cools the charge on its way to the plenum, and the water/methanol injection lowers intake temperature further. The supercharger also runs its own oil cooler and traction fluid, kept apart from the S65 engine oil.

Who should install the kit and how long does it take to arrive?

Active Autowerke requires installation by an approved dealer to keep the warranty, which covers kit components for one year with unlimited mileage. Every E9X kit is built to order, and Active Autowerke allows up to six weeks before it ships.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Active Autowerke Gen 2 Level 4 Supercharger Kit for E90 / E92 / E93 BMW M3

Active Autowerke’s Gen 2 Level 4 Supercharger Kit for E90 / E92 / E93 BMW M3 is the strongest of the Miami company’s S65 kits, pairing a Rotrex C38-92R with water/methanol injection, an upgraded pulley and its own software to run 12 psi. Charge air reaches the V8 through a matte wrinkle black plenum that replaces the factory airbox and feeds eight velocity stacks. It is built for an owner who has already dealt with the rod bearings and wants the most power Active Autowerke offers for the E9X; the Gen 2 Level 2 at 8 psi or the Gen 2 Level 3 at 9 psi asks less of the engine.

Design and Performance

The Rotrex turns on its own eight-rib belt rather than the accessory drive and keeps an independent supply of longlife traction fluid with a separate cooler. Boosted air crosses a front-mount air-to-air intercooler on 3 inch piping, and the methanol spray then cools the charge again to hold off detonation.

Features

Rotrex C38-92R centrifugal supercharger on CNC-machined, hard-anodized brackets
Custom-calibrated water/methanol injection with an upgraded pulley
Active Autowerke software for the MSS60 engine computer, kept inside the factory OBDII parameters
Active Autowerke blow-off valves and bypass valve
Cold air intake box with an Active Autowerke spec filter and oil breather system
Spark plugs, a new AN-fitted oil line, all hoses, clamps and mounting hardware, and a step-by-step manual

Specifications

Boost: 12 psi
Quoted output: over 700 hp
Quoted torque: 480 lb-ft
Velocity stacks: 8
Fuel injectors: 8

Applications

BMW M3: E90 | 2008-2011 | 4.0L S65
BMW M3: E92 | 2008-2013 | 4.0L S65
BMW M3: E93 | 2008-2013 | 4.0L S65

Notes

Active Autowerke does not say whether the Level 4 Supercharger Kit for E90 / E92 / E93 M3 figures are crank or wheel numbers, and notes they vary with weather and conditions
Calibrated for 93 octane (98 RON) or 91 octane pump fuel; race fuel and export calibrations are available
Active Autowerke recommends a high-flow catted mid-section, such as its AFlow Catted X-Pipe for the E9X M3 or GESI Catted X-Pipe
Active Autowerke recommends addressing S65 rod bearing condition before installation
Installation by an approved Active Autowerke dealer keeps the one-year, unlimited-mileage warranty on kit components. Allow up to 6 weeks for the build.

Frequently Asked Questions

Does the Level 4 Supercharger Kit for E90 / E92 / E93 M3 include a tune? Yes. Active Autowerke ships its MSS60 software with the Level 4 Supercharger Kit for E90, E92 and E93 M3 models, together with eight Bosch Motorsport injectors for the added fuel. The calibration is written for 93 or 91 octane pump fuel, and race fuel versions are available.
Should the S65 rod bearings be replaced before supercharging? Yes. Active Autowerke recommends addressing the condition of the S65 rod bearings before any engine modification, and this kit adds 12 psi of boost. An E9X M3 with no record of bearing service should have them inspected or replaced before the supercharger goes on.
What separates the Level 2, Level 3 and Level 4 kits? Level 2 runs a Rotrex C38-92 at 8 psi without water/methanol injection. Level 3 keeps the C38-92 and adds water/methanol injection with an upgraded pulley for 9 psi. Level 4 moves to the C38-92R at 12 psi with injection, the upgraded pulley and custom software.
Does the kit use an intercooler? Yes. A front-mount air-to-air intercooler cools the charge on its way to the plenum, and the water/methanol injection lowers intake temperature further. The supercharger also runs its own oil cooler and traction fluid, kept apart from the S65 engine oil.
Who should install the kit and how long does it take to arrive? Active Autowerke requires installation by an approved dealer to keep the warranty, which covers kit components for one year with unlimited mileage. Every E9X kit is built to order, and Active Autowerke allows up to six weeks before it ships.

About Active Autowerke

Active Autowerke was founded in Miami, Florida in 1981 by brothers Mike and Karl Hugh as a BMW service shop, and turned to performance in late 1995 when Karl, a University of Miami engineering graduate, led its first M3 and 325i turbo kits. Supercharger kits for the E36, E46 and E9X followed, and its Signature Equal Length mid-pipe is protected by US Patent 11248511 and European and UK Patent 3882441.
