Are fog light bezels needed for the Brake Cooling Kit for GR / GV?

Yes, if the car does not already have them. The Brake Cooling Kit for GR / GV takes its air through the fog light openings, so an STI without OEM fog light bezels needs OEM or similar bezels before the kit can be fitted. Verus Engineering bought OEM bezels for both sides of its own car and had them paint matched.

Can I keep the factory washer fluid reservoir with this kit?

Yes. Verus Engineering notes that the OEM washer fluid reservoir can be retained on the GR and GV STI with this kit installed. The ducting runs from the fog light opening through the inner fender line to the backing plate, using pre-cut neoprene and high-temperature silicone hose.

Why does brake cooling help on the stock STI rotors?

The vanes inside the stock STI rotors are small next to those in a big brake kit, and small vanes flow less air. Verus Engineering found with tufts and thermal imaging that pushing outside air into the rotor center made the factory rotors run much cooler, both directly after braking and after a short drive.

Does the kit work better at high speed?

Yes. The kit runs on frontal ambient air, and both its pressure and flow rate climb with road speed, so Verus Engineering saw it do significantly more at high speed than around town. That is the condition a track day creates, with repeated heavy stops from speed.

What is the GR / GV brake cooling kit made from?

Each stainless steel backing plate carries a 316L stainless duct, 3D printed and riveted on by Verus Engineering. The fender pancake ducts and fog light ducts are hard plastic, the fog light run uses 3 inch neoprene hose and the backing plate run uses 2.5 inch high-temperature silicone, all secured with stainless clamps.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Verus Engineering Full Brake Cooling Kit for GR / GV Subaru WRX STI

Verus Engineering’s Full Brake Cooling Kit for GR / GV Subaru WRX STI feeds the front rotors of the 2008 to 2014 STI from the factory fog light openings, carrying the air through a duct in the inner fender line to stainless backing plates with 3D printed 316L ducts riveted on. Verus kept the route as short as the chassis allows, and the factory washer fluid reservoir can stay where it is. Testing showed the gains rise with speed, so the kit earns most on an STI that sees open tracks, and track customers have told Verus of reduced fade, fewer cracked rotors, improved pad wear and less boiled fluid.

Features

Fog light inlet draws from the high-pressure zone of the front bumper
Ducted air delivered straight to the center of the rotor
Installs in a few hours with basic hand tools

What’s Included

Stainless backing plates, 316L 3D printed ducts riveted on (L/R)
Fog light ducts (x2)
Fog light duct brackets (x2)
Fender pancake ducts (x2)
3.0 inch neoprene brake hose, pre-cut (x2)
2.5 inch high-temperature silicone brake hose, pre-cut (x2)
Hose clamps in stainless, 3.0 inch (x4) and 2.5 inch (x4)
Hardware kit with all mounting pieces

Applications

Subaru WRX STI: GR hatchback | 2008-2014
Subaru WRX STI: GV sedan | 2011-2014

Notes

Fog light bezels are not included; an STI without OEM fog light bezels needs OEM or equivalent bezels, which Verus bought from Subaru and paint matched for its own car
The Brake Cooling Kit for GR / GV keeps the factory washer fluid reservoir in place
An informative packet and install manual come from Verus, which builds the kit in the U.S.A
Add front downforce to match with the Verus Engineering Front Splitter Kit for GR / GV Subaru WRX STI
See every Verus Engineering part for the GR / GV Subaru WRX STI
Verus covers its parts with a 1-year limited warranty against manufacturing defects

Frequently Asked Questions

Are fog light bezels needed for the Brake Cooling Kit for GR / GV? Yes, if the car does not already have them. The Brake Cooling Kit for GR / GV takes its air through the fog light openings, so an STI without OEM fog light bezels needs OEM or similar bezels before the kit can be fitted. Verus Engineering bought OEM bezels for both sides of its own car and had them paint matched.
Can I keep the factory washer fluid reservoir with this kit? Yes. Verus Engineering notes that the OEM washer fluid reservoir can be retained on the GR and GV STI with this kit installed. The ducting runs from the fog light opening through the inner fender line to the backing plate, using pre-cut neoprene and high-temperature silicone hose.
Why does brake cooling help on the stock STI rotors? The vanes inside the stock STI rotors are small next to those in a big brake kit, and small vanes flow less air. Verus Engineering found with tufts and thermal imaging that pushing outside air into the rotor center made the factory rotors run much cooler, both directly after braking and after a short drive.
Does the kit work better at high speed? Yes. The kit runs on frontal ambient air, and both its pressure and flow rate climb with road speed, so Verus Engineering saw it do significantly more at high speed than around town. That is the condition a track day creates, with repeated heavy stops from speed.
What is the GR / GV brake cooling kit made from? Each stainless steel backing plate carries a 316L stainless duct, 3D printed and riveted on by Verus Engineering. The fender pancake ducts and fog light ducts are hard plastic, the fog light run uses 3 inch neoprene hose and the backing plate run uses 2.5 inch high-temperature silicone, all secured with stainless clamps.

About Verus Engineering

Verus Engineering designs aerodynamic and performance parts in Indianapolis, Indiana. Two engineers founded it in late 2014 as Velox Motorsports and renamed it in 2017 after a trademark dispute; verus is Latin for true or complete. Each design starts from a 3D scan of the car, is developed with CFD and finite element analysis and is validated on track, across more than 20 platforms from the GR86 to the C8 Corvette.
