Are springs included?

Yes. Four TEIN springs come with the dampers: 12.0 kgf/mm (672 lbs/in) at the front, 175 mm long, and 14.0 kgf/mm (784 lbs/in) at the rear, 200 mm long. All four have a 70 mm inner diameter and sit on wrought aluminium spring seats.

How does the kit change the way the NSX corners?

TEIN set the damping to move the factory car from a slight reverse-steer tendency toward near-neutral cornering. Behaviour at the limit is calmer, which improves cornering control, and the 16-level adjuster lets the driver fine tune the balance for road or track use.

How much lower will the NSX sit?

TEIN recommends 0.8 to 1.6 inches lower at the front and 1.0 to 1.8 inches lower at the rear. The front can range from 4.0 inches below to 1.8 inches above stock, and the rear from 3.9 to 0.2 inches below stock height.

Do the Mono Sport Coilovers for NA1 also fit the NA2?

Yes. The TEIN Mono Sport Coilovers for NA1 are listed for the US NA1 NSX from 1991 to 1996 and the NA2 from 1997 to 2005, plus Japanese-market NSX models from 1990 to 2005, including the Type R and Type S.

Can the damping be adjusted from the cabin?

Yes, with an optional TEIN EDFC controller, which also doubles the range from 16 to 32 levels. EDFC ACTIVE and ACTIVE PRO take it to 64 levels and adjust automatically by G-force and speed. Without a controller, each knob is turned by hand.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

TEIN Mono Sport Coilovers for NA1 / NA2 Acura NSX

TEIN’s Mono Sport Coilovers for NA1 and NA2 Acura NSX move the car from the slight reverse-steer tendency of its factory setup toward near-neutral cornering. The damping also calms how the NSX behaves at the limit, which TEIN says improves cornering control. Pillow ball upper mounts are fitted at all four corners. The kit is aimed at owners who drive the NSX hard on winding roads or at track days; a car kept for gentle weekend drives has less to gain.

Inside the Dampers

Each damper is mono-tube, with gas and oil kept apart so damping holds steady when the car is worked hard. Full-length bodies set ride height by case length, so stroke and spring preload stay where TEIN designed them. Shell cases are high-strength STKM13C steel with ZTP coating on the thread, and each kit gets final assembly in a clean room with air showers.

Features

Pillow ball upper mounts at the front and rear of the car
Wrought aluminium spring seats turning on low-friction hard-resin thrust washers
Supplied wrench takes a 12.7 mm square drive for a spinner or torque wrench
Model-specific dust boots shield the damper shafts
Overhaulable and revalvable, so a worn set can be rebuilt rather than replaced

Specifications

Front spring: 12.0 kgf/mm (672 lbs/in), 175 mm, 70 mm ID
Rear spring: 14.0 kgf/mm (784 lbs/in), 200 mm, 70 mm ID
Front ride height range: -4.0 to +1.8 in (recommended -1.6 to -0.8)
Rear ride height range: -3.9 to -0.2 in (recommended -1.8 to -1.0)
Damping adjustment: 16 levels (32 with EDFC, 64 with EDFC ACTIVE)

What’s Included

Mono-tube shock absorbers (x4)
Springs (x4)

Applications

Acura NSX: NA1 | 1991-1996 | 3.0L
Acura NSX: NA2 | 1997-2005 | 3.2L
Honda NSX (Japan-market, incl. Type R and Type S): NA1 / NA2 | 1990-2005 | 3.0L / 3.2L

Notes

This kit is built to order by TEIN; lead times vary and the order cannot be cancelled or returned
EDFC controllers for the TEIN Mono Sport Coilovers for NA1 are sold separately
More TEIN kits for Honda and Acura are in the TEIN range

Frequently Asked Questions

Are springs included? Yes. Four TEIN springs come with the dampers: 12.0 kgf/mm (672 lbs/in) at the front, 175 mm long, and 14.0 kgf/mm (784 lbs/in) at the rear, 200 mm long. All four have a 70 mm inner diameter and sit on wrought aluminium spring seats.
How does the kit change the way the NSX corners? TEIN set the damping to move the factory car from a slight reverse-steer tendency toward near-neutral cornering. Behaviour at the limit is calmer, which improves cornering control, and the 16-level adjuster lets the driver fine tune the balance for road or track use.
How much lower will the NSX sit? TEIN recommends 0.8 to 1.6 inches lower at the front and 1.0 to 1.8 inches lower at the rear. The front can range from 4.0 inches below to 1.8 inches above stock, and the rear from 3.9 to 0.2 inches below stock height.
Do the Mono Sport Coilovers for NA1 also fit the NA2? Yes. The TEIN Mono Sport Coilovers for NA1 are listed for the US NA1 NSX from 1991 to 1996 and the NA2 from 1997 to 2005, plus Japanese-market NSX models from 1990 to 2005, including the Type R and Type S.
Can the damping be adjusted from the cabin? Yes, with an optional TEIN EDFC controller, which also doubles the range from 16 to 32 levels. EDFC ACTIVE and ACTIVE PRO take it to 64 levels and adjust automatically by G-force and speed. Without a controller, each knob is turned by hand.

About TEIN

TEIN was founded in Yokohama, Japan, in 1985 by former rally mechanic Hakaru Ichino, joined soon after by driver Yoshio Fujimoto. The team reached the World Rally Championship in 1989, and in 1995 Fujimoto won the Safari Rally in a Toyota Celica GT-FOUR, the first Japanese driver to do so. TEIN launched its own dampers in 1990 and came to supply around 80 percent of the dampers in the N1 Taikyu endurance series. TEIN USA has served the Americas from Downey, California, since 2001.
