Does the Venturi Throttle Body for AP2 need a tune?

Spoon lists no calibration change in its fitting information for the venturi throttle body for AP2, and it supplies the gasket for a direct swap. A car already running a custom map should still be reviewed by its tuner afterwards, because a larger bore changes the airflow at any given pedal position.

Will it fit a 2004 or 2005 S2000?

No. Spoon registers the AP2 from chassis AP2-100, and Go Tuning, the sole US distributor for Spoon, sells this part for 2006 to 2009 model year cars only. The 2004 and 2005 US cars are absent from both lists, so BA will not ship it for one of them.

How much larger is it than the stock throttle body?

The bore grows from 67 mm to 70 mm and the butterfly from 64 mm to 66 mm. Worked out from those diameters, that is roughly 9 percent more bore area. The venturi shape and polished walls add to the effect by letting air through the larger opening with less turbulence.

Why does Spoon mirror-finish the inside?

Rough machined walls slow the boundary layer of air and create small eddies. By diamond cutting the bore to a mirror surface, Spoon reduces that friction so more of the opening carries useful flow. It is the same thinking Spoon applies to its intake and exhaust parts, taken to the throttle.

Is it worth fitting to an otherwise stock S2000?

It depends on the plan. On a standard AP2 the throttle is not the main restriction, so the change will be modest. It earns its price on a car with a freer intake and exhaust, or one heading for further engine work, where the factory bore becomes the narrowest point in the system.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Spoon Sports Venturi Throttle Body for AP2 Honda S2000

The Spoon Sports Venturi Throttle Body for AP2 Honda S2000, catalogued by Spoon as the Venturi Big Throttle Body, opens the 2.2-litre F22C intake from a 67 mm bore to 70 mm and replaces the 64 mm butterfly with a 66 mm one. Spoon arrived at the design after re-examining its earlier throttle bodies through repeated testing. The bore now follows a venturi profile to improve cylinder filling, and its walls are diamond-cut to a mirror finish so incoming air meets as little friction as possible. The butterfly is an oval plate cut on an angle, which lets it close a larger bore while matching the durability of the factory part. On an AP2 already running an intake and exhaust it removes a restriction every gram of air must pass; on a standard car the gain will be smaller.

Features

Venturi bore profile for better cylinder filling
Diamond-cut mirror finish on the bore walls
Angled oval butterfly sized for the larger bore
Durability engineered to match the factory part
Gasket supplied for a direct swap

Specifications

Bore: 70 mm, stock 67 mm
Butterfly: 66 mm, stock 64 mm
Bore profile: venturi
Internal finish: diamond-cut mirror
Gasket: included
Chassis: AP2-100 onward

Applications

Honda S2000: AP2 | 2005-2009 | 2.2L F22C

Notes

Spoon registers the Venturi Throttle Body for AP2 from chassis AP2-100 onward, and Go Tuning sells it for the 2006 to 2009 US model years; the 2004 and 2005 US cars are not listed by either source
A throttle body gasket is included

Frequently Asked Questions

Does the Venturi Throttle Body for AP2 need a tune? Spoon lists no calibration change in its fitting information for the venturi throttle body for AP2, and it supplies the gasket for a direct swap. A car already running a custom map should still be reviewed by its tuner afterwards, because a larger bore changes the airflow at any given pedal position.
Will it fit a 2004 or 2005 S2000? No. Spoon registers the AP2 from chassis AP2-100, and Go Tuning, the sole US distributor for Spoon, sells this part for 2006 to 2009 model year cars only. The 2004 and 2005 US cars are absent from both lists, so BA will not ship it for one of them.
How much larger is it than the stock throttle body? The bore grows from 67 mm to 70 mm and the butterfly from 64 mm to 66 mm. Worked out from those diameters, that is roughly 9 percent more bore area. The venturi shape and polished walls add to the effect by letting air through the larger opening with less turbulence.
Why does Spoon mirror-finish the inside? Rough machined walls slow the boundary layer of air and create small eddies. By diamond cutting the bore to a mirror surface, Spoon reduces that friction so more of the opening carries useful flow. It is the same thinking Spoon applies to its intake and exhaust parts, taken to the throttle.
Is it worth fitting to an otherwise stock S2000? It depends on the plan. On a standard AP2 the throttle is not the main restriction, so the change will be modest. It earns its price on a car with a freer intake and exhaust, or one heading for further engine work, where the factory bore becomes the narrowest point in the system.

About Spoon Sports

Spoon Sports was founded in 1988 in Suginami, Tokyo, by Tatsuru Ichishima, a former Honda race car tester and driver, with backing from Honda and Mugen. The company has raced Hondas from its first season, when Ichishima’s own Civic became the first Civic to enter the Japan Touring Car Championship, and its Type One workshop, opened in 2001, services and tunes the cars its parts are developed on. Spoon builds engine, drivetrain, exhaust, chassis and aero parts for Honda models and proves them on circuits and in endurance racing, including the 25 Hours of Thunderhill.
