What does the LEGAMAX Premium with Center Pipe include?

HKS supplies the LEGAMAX Premium with Center Pipe, part 32018-AT040, as two pieces: the rear main muffler with its twin 124mm slotted tails and the dual center pipe that runs from 60mm down to 54mm. The main muffler alone is sold as part 32018-AT039 for owners keeping the factory center section.

How loud is this system compared to the factory exhaust?

HKS measured 91 dB against 86 dB for the factory system on its close test, and 56 dB against 54 dB at idle. The slotted tails are there to cancel low-frequency resonance, so HKS pitches the LEGAMAX Premium as quieter inside the cabin while sounding livelier at high speed.

Does this exhaust fit the 2022 and newer GR86 or BRZ?

No. HKS lists part 32018-AT040 for the FA20 ZN6 Toyota 86 and Scion FR-S and the ZC6 Subaru BRZ only. The FA24 ZN8 GR86 and ZD8 BRZ take different HKS exhausts, including the LEGAMAX Sports for those cars, which Bulletproof Automotive also carries.

How much does the system weigh?

HKS lists the complete system at 38.6lb, or 17.5kg, for the muffler and center pipe together. HKS does not publish a factory figure for comparison, so this system is chosen for its tone and flow rather than for weight; the Hi-Power SPEC-L II is the lighter HKS option for the FA20 cars.

Does the FA20 need a tune after installing this system?

No. HKS lists no tuning requirement for part 32018-AT040, and the kit includes no engine management. HKS credits the 40% cut in exhaust pressure loss with better low-speed torque and throttle response on the factory calibration, and owners who tune the engine later can keep the system on the car.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

HKS LEGAMAX Premium with Center Pipe for ZN6 Toyota 86, Scion FR-S and ZC6 Subaru BRZ

HKS’s LEGAMAX Premium with Center Pipe for ZN6 Toyota 86, Scion FR-S and ZC6 Subaru BRZ replaces the factory center section and rear muffler on the FA20 coupes with a two-piece SUS304 stainless system, finished with a pair of 124mm slotted tails. HKS built it around the idea of best looks with power: the slotted tails cancel low-frequency resonance in the cabin, while a 40% cut in exhaust pressure loss sharpens low-speed torque and response. It suits the owner who wants a composed, finished rear, a calm cabin and a livelier note once the car is moving quickly.

Features

Dual center pipes stepping from 60mm to 54mm, matched to the LEGAMAX Premium main muffler
Large 124mm slotted tails that HKS uses to cancel low-frequency exhaust resonance
Exhaust pressure loss cut by 40% compared to the factory system, according to HKS
Tuned by HKS for less intrusive cabin sound and a livelier exhaust note at high speed

Specifications

Center Pipe Diameter: 60mm to 54mm, dual
Tails: 124mm slotted, left and right
Main Material: SUS304 stainless steel
Weight: 38.6lb (17.5kg), two pieces
Sound Level, Factory System: 86 dB (54 dB at idle), HKS measurement
Sound Level, HKS: 91 dB (56 dB at idle), HKS measurement
Minimum Road Clearance: 125mm at the center pipe

Applications

Scion FR-S: ZN6 | 2013-2016 | FA20
Subaru BRZ: ZC6 | 2013-2020 | FA20
Toyota 86: ZN6 | 2017-2020 | FA20

Notes

The LEGAMAX Premium with Center Pipe includes the center section; the HKS LEGAMAX Premium Exhaust is the main muffler alone
Sound figures are HKS measurements on Japanese-market cars and vary with the vehicle and test setup
This exhaust is intended for off-road or competition use where emissions laws apply, and the buyer is responsible for checking local emissions and noise regulations before installation
JASMA Certification: JQR20122035

Frequently Asked Questions

What does the LEGAMAX Premium with Center Pipe include? HKS supplies the LEGAMAX Premium with Center Pipe, part 32018-AT040, as two pieces: the rear main muffler with its twin 124mm slotted tails and the dual center pipe that runs from 60mm down to 54mm. The main muffler alone is sold as part 32018-AT039 for owners keeping the factory center section.
How loud is this system compared to the factory exhaust? HKS measured 91 dB against 86 dB for the factory system on its close test, and 56 dB against 54 dB at idle. The slotted tails are there to cancel low-frequency resonance, so HKS pitches the LEGAMAX Premium as quieter inside the cabin while sounding livelier at high speed.
Does this exhaust fit the 2022 and newer GR86 or BRZ? No. HKS lists part 32018-AT040 for the FA20 ZN6 Toyota 86 and Scion FR-S and the ZC6 Subaru BRZ only. The FA24 ZN8 GR86 and ZD8 BRZ take different HKS exhausts, including the LEGAMAX Sports for those cars, which Bulletproof Automotive also carries.
How much does the system weigh? HKS lists the complete system at 38.6lb, or 17.5kg, for the muffler and center pipe together. HKS does not publish a factory figure for comparison, so this system is chosen for its tone and flow rather than for weight; the Hi-Power SPEC-L II is the lighter HKS option for the FA20 cars.
Does the FA20 need a tune after installing this system? No. HKS lists no tuning requirement for part 32018-AT040, and the kit includes no engine management. HKS credits the 40% cut in exhaust pressure loss with better low-speed torque and throttle response on the factory calibration, and owners who tune the engine later can keep the system on the car.

About HKS

HKS is a Japanese performance engineering brand founded in 1973 and headquartered in Fujinomiya, Shizuoka, with a long-standing reputation for developing high-quality aftermarket parts and motorsport-proven technology for enthusiast and professional applications. Known for innovations in turbocharging and engine performance, HKS produces a broad range of components including exhaust systems, turbo kits, electronics / engine management, and suspension solutions, with product development heavily influenced by decades of involvement in racing disciplines such as circuit time attack, drag, and drifting.
