HKS HIPERMAX S Pillow Coilover Kit for VA Subaru WRX / STI [80300-AF009P]

HKS HIPERMAX S Pillow Coilover Kit for VA Subaru WRX / STI [80300-AF009P]

The HKS HIPERMAX S Pillow Coilover Kit for the VA Subaru WRX and STI is engineered to deliver exceptional performance, comfort and durability for both street and spirited driving. Featuring a pillow ball front upper mount and an inverted single-tube design, this system ensures precise handling and improved steering response. With 30 levels of adjustable damping and an adjustable shock body, drivers can fine-tune ride quality and stance to their exact preference. HKS incorporates advanced Dual PVS technology for enhanced comfort without sacrificing performance, while the PNE coating provides superior resistance against wear and corrosion, ensuring long-lasting reliability.

Dual PVS

• HKS has advanced the existing preload valve system into a dual preload valve system, effectively suppressing unnecessary damping force generated during higher piston speeds. This innovation delivers significant improvements in ride comfort without compromising driving performance.

Wide Range Damping Force Adjustment

• An improved Needle jet design expands the available range of damping force adjustment, enabling the suspension to perform effectively across a wider variety of driving conditions.

Evolution of Bump Stop Rubber

• A newly developed bump stop rubber design minimizes body roll while enhancing ride comfort, achieving results that conventional hydro bump stop rubber cannot match.

Low Friction Technology

• Through the use of advanced tribology technology, HKS has achieved greater durability and reduced friction compared to conventional products. This advancement enhances both ride quality and handling performance.

Warranty

• The HIPERMAX S Series is backed by a three-year warranty, supported by optimized internal components and improved manufacturing quality.

Features

• Pillow ball upper mount (front)
• 30 levels adjustable damping
• Adjustable shock-body
• DUAL PVS
• PNE coated
• 3-year warranty

Specifications

• Spring Rate [N/mm(kgf/mm)]
  • F = 88 (9)
  • R = 69 (7)
• Spring Length (mm)
  • F = 220 (barrel)
  • R = 170 (straight)
• Upper Mount
  • F = spherical bearing
  • R = rubber

Applications

• Subaru WRX: VAG (2015-2021)
• Subaru WRX STI: VAB (2015-2021)

Notes

• After installation Subaru EyeSight may not function properly, please refer to the factory manual
• Spherical bearings are subject to wear over time, but replacement units are available for purchase separately
• This kit is a special version of the HIPERMAX S pillow upper mount, standard mount is available here
