Which car is the GiroDisc Z/28 Rear Iron Rotor Conversion made for?

The GiroDisc Z/28 Rear Iron Rotor Conversion is made for the fifth-generation Chevrolet Camaro Z/28. It replaces the factory carbon-ceramic rear discs with two-piece iron rotors, each built from a slotted cast iron ring floating on an aluminum hat. Twelve drive pins carry each ring.

Should the front and rear conversions be done together?

Yes, in most cases. Converting both axles puts the whole car on iron rings with one service routine, and GiroDisc offers the A1-172 front conversion for that purpose. Contact Bulletproof Automotive to confirm the full parts list for a four-corner conversion.

How is the rear ring held on the hat?

Twelve high-strength alloy steel drive pins, made by GiroDisc in the USA and cadmium plated for corrosion resistance, hold each ring. They transmit braking load while allowing axial and radial float, and class 12.9 cap screws with hardened washers secure every pin.

Is the rear conversion noisy at low speed?

No. Anti-noise spring washers sit on the rotor side of every drive pin. They let the iron ring grow as it heats but hold it firmly when cold, which removes the clatter often linked with floating rotors on a road-driven car.

How should worn rear rings be dealt with?

Replace the rings when they reach the minimum thickness marked on the hat and ring edge, or if a crack reaches the edge. GiroDisc does not list a separate ring set for this part, so contact Bulletproof Automotive for the correct replacement when the time comes.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

GiroDisc Z/28 Rear Iron Rotor Conversion for 5th Gen Chevrolet Camaro

GiroDisc’s Z/28 Rear Iron Rotor Conversion for the fifth-generation Chevrolet Camaro takes the rear axle off the factory carbon-ceramic discs and onto two-piece iron rotors. Each slotted ring is cast from GiroDisc’s proprietary iron, poured in the USA and machined in Bellingham, Washington, then floated on a US-sourced 6061-T6 hat with twelve drive pins. Paired with the front conversion, it puts the whole Z/28 on iron for owners who would sooner replace rings than ceramic discs.

Construction

Twelve high-strength alloy steel drive pins, made by GiroDisc and cadmium plated, carry the braking load while allowing the ring to float axially and radially. Class 12.9 cap screws with hardened washers secure them, and anti-noise spring washers on the rotor side stop the rattle floating rotors can make when cold. Curved vanes pump air from the hub through the disc.

Features

Converts the Z/28 rear axle from carbon-ceramic to iron
Twelve cadmium-plated drive pins per rotor
Slotted ring poured in the USA, machined in-house
Curved cooling vanes developed in racing
Anti-noise spring washers for quiet operation
Reusable 6061-T6 aluminum hats

What’s Included

Rear rotor assemblies (L/R)

Applications

Chevrolet Camaro Z/28: 5th Gen | 7.0L V8

Notes

The Z/28 Rear Iron Rotor Conversion is listed for the fifth-generation Camaro Z/28 with factory carbon-ceramic brakes
Contact Bulletproof Automotive before ordering to confirm the installation requirements for your car
The GiroDisc Z/28 front iron rotor conversion completes the set
Cap screws are never tightened beyond 60 in-lb, or 7 Nm
Stock photography may not depict the actual product

Frequently Asked Questions

Which car is the GiroDisc Z/28 Rear Iron Rotor Conversion made for? The GiroDisc Z/28 Rear Iron Rotor Conversion is made for the fifth-generation Chevrolet Camaro Z/28. It replaces the factory carbon-ceramic rear discs with two-piece iron rotors, each built from a slotted cast iron ring floating on an aluminum hat. Twelve drive pins carry each ring.
Should the front and rear conversions be done together? Yes, in most cases. Converting both axles puts the whole car on iron rings with one service routine, and GiroDisc offers the A1-172 front conversion for that purpose. Contact Bulletproof Automotive to confirm the full parts list for a four-corner conversion.
How is the rear ring held on the hat? Twelve high-strength alloy steel drive pins, made by GiroDisc in the USA and cadmium plated for corrosion resistance, hold each ring. They transmit braking load while allowing axial and radial float, and class 12.9 cap screws with hardened washers secure every pin.
Is the rear conversion noisy at low speed? No. Anti-noise spring washers sit on the rotor side of every drive pin. They let the iron ring grow as it heats but hold it firmly when cold, which removes the clatter often linked with floating rotors on a road-driven car.
How should worn rear rings be dealt with? Replace the rings when they reach the minimum thickness marked on the hat and ring edge, or if a crack reaches the edge. GiroDisc does not list a separate ring set for this part, so contact Bulletproof Automotive for the correct replacement when the time comes.

About GiroDisc

GiroDisc designs, manufactures, and sells 2-piece, fully floating brake rotors for a wide range of performance vehicles. Every major component, including the hats, rotor rings, and drive pins, is manufactured in-house at their facility in Bellingham, Washington, from domestically sourced materials. GiroDisc rotors use a proprietary high-carbon iron ring formulated for superior metallurgy and thermal performance, paired with reusable machined-aluminum hats that reduce the long-term cost of maintaining a high-performance brake system. The 2-piece floating design sheds unsprung and rotating mass while remaining street-friendly, delivering race-proven braking for track and street use alike.
