How much horsepower does the 88mm GTX5533R Gen II Super Core support?

Garrett rates the 88mm GTX5533R Gen II Super Core at 1000 to 1900 horsepower on 3.0L to 12.0L engines, with compressor flow up to 172 lbs/min. The rating is based on compressor choke flow and represents potential flywheel horsepower rather than a guaranteed result.

88mm or 85mm: what is the trade?

Both use the 133mm exducer and the 0.88 A/R compressor housing. The 88mm wheel, 44 trim, adds about 12 lbs/min of flow and 140 horsepower of rating over the 85mm, at a small cost in boost response. If the target sits above roughly 1700 horsepower, the 88mm is the better fit.

What is the difference between this core and the SFI version?

Garrett offers SFI supercore and turbine options for the GTX5533R, and Turn 14 lists 851285-5007S as the 88mm SFI core. This part, 851285-5002S, is the standard 88mm core. Racers whose sanctioning body requires SFI-certified turbocharger parts should choose the SFI version.

Will my GTX55 turbine housing fit?

Yes. Garrett lists its GTX55 turbine kits as interchangeable with GT and GTX 5533 and 5544 supercores, and states Gen II GTX turbochargers work with existing GT and GTX turbine housing kits. That covers V-band and T6 inlet housings from 1.12 to 1.40 A/R.

Should I fit a speed sensor?

It is a good idea. Garrett caps the GTX5533R Gen II at 84,000 rpm and states that higher speeds are at the risk of the owner. The compressor housing has a machined port, plugged from the factory and opened with a 5mm Allen key, ready for a Garrett sensor sold separately.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Garrett GTX5533R Gen II Super Core, 88mm Compressor Inducer

Garrett’s GTX5533R Gen II Super Core in 88mm form steps up from the entry 85mm wheel to a 44 trim inducer, flowing 172 lbs/min, and Garrett rates it at 1000 to 1900 horsepower on engines from 3.0L to 12.0L. It still uses the 0.88 A/R compressor housing, so it keeps much of the smaller core’s response while adding headroom. That makes it a strong match for a big-block or large LS-style V8 targeting 1500 to 1800 horsepower. A build pushing past 2000 horsepower should look at the 91mm and larger GTX5533R cores.

Compressor Side

Garrett machines the inlet, outlet and ported shroud of the Gen II compressor housing, and describes the shroud as an improved design for surge resistance. The backplate is lightweight billet and the compressor outlet is a V-band joint. Garrett also offers SFI supercore and turbine options for this size, listed separately.

Features

88mm inducer, 44 trim, flowing up to 172 lbs/min
0.88 A/R compressor housing with a V-band outlet
Fully machined speed sensor port, plugged from the factory

Specifications

Compressor inducer and exducer: 88mm and 133mm
Compressor trim: 44
Compressor housing A/R: 0.88
Turbine inducer and exducer: 112mm and 102mm
Turbine trim: 84
Compressor flow: Up to 172 lbs/min
Maximum turbocharger speed: 84,000 rpm

Applications

The GTX5533R Gen II Super Core is not vehicle specific. Garrett matches it to engine size and output:

Engine displacement: 3.0L to 12.0L
Power range: 1000 to 1900 horsepower (Garrett rating)
Garrett GTX55 turbine kits: V-band inlet in 1.24 or 1.40 A/R, standard or long outlet with cross bolts; T6 inlet in 1.12, 1.24 or 1.40 A/R; all with a V-band outlet

Notes

The turbine housing is not included; Garrett lists seven GTX55 turbine housings for 5533 and 5544 cores
Every GTX55 housing Garrett lists is free float, so an external wastegate is required
The Garrett speed sensor kit is sold separately
Garrett states that running above 84,000 rpm is at the owner’s risk and can cause damage and premature failure
The SFI version of the 88mm GTX5533R Gen II is also listed

Frequently Asked Questions

How much horsepower does the 88mm GTX5533R Gen II Super Core support? Garrett rates the 88mm GTX5533R Gen II Super Core at 1000 to 1900 horsepower on 3.0L to 12.0L engines, with compressor flow up to 172 lbs/min. The rating is based on compressor choke flow and represents potential flywheel horsepower rather than a guaranteed result.
88mm or 85mm: what is the trade? Both use the 133mm exducer and the 0.88 A/R compressor housing. The 88mm wheel, 44 trim, adds about 12 lbs/min of flow and 140 horsepower of rating over the 85mm, at a small cost in boost response. If the target sits above roughly 1700 horsepower, the 88mm is the better fit.
What is the difference between this core and the SFI version? Garrett offers SFI supercore and turbine options for the GTX5533R, and Turn 14 lists 851285-5007S as the 88mm SFI core. This part, 851285-5002S, is the standard 88mm core. Racers whose sanctioning body requires SFI-certified turbocharger parts should choose the SFI version.
Will my GTX55 turbine housing fit? Yes. Garrett lists its GTX55 turbine kits as interchangeable with GT and GTX 5533 and 5544 supercores, and states Gen II GTX turbochargers work with existing GT and GTX turbine housing kits. That covers V-band and T6 inlet housings from 1.12 to 1.40 A/R.
Should I fit a speed sensor? It is a good idea. Garrett caps the GTX5533R Gen II at 84,000 rpm and states that higher speeds are at the risk of the owner. The compressor housing has a machined port, plugged from the factory and opened with a 5mm Allen key, ready for a Garrett sensor sold separately.

About Garrett

Garrett Motion has turbocharged engines since 1955, when its T15 was matched to the Caterpillar D9 crawler, and in 1962 a Garrett turbocharger went into the Oldsmobile Jetfire Turbo Rocket, the first turbocharged production car. Garrett has supplied turbocharging in Formula 1 with Scuderia Ferrari, the FIA World Rally Championship and the 24 Hours of Le Mans. It has operated as a stand-alone company since 2018, and its technology is fitted to around 150 million vehicles worldwide.
