What engines suit the 1.06 A/R V-band G40 Turbine Housing Kit?

Larger ones. The 1.06 A/R G40 Turbine Housing Kit suits engines toward the upper part of the 2.0L to 6.0L range Garrett gives for G40 cores, or high-rpm builds on smaller engines. It flows more than the 0.85 and 0.95 sizes, so boost comes in somewhat later.

Is the G40 turbine wheel an upgrade over the GTX4088R?

Garrett states that the G-Series turbine aero on the G40 flows 16 percent more than the GTX4088R, and that the Inconel wheel with a 77mm inducer flows up to 43 lbs per minute. This housing is made for that wheel, which sits in the G40 super core sold separately.

Will a GXR40-64 fit if I start with a G40-1150?

Yes. Garrett states that the GXR40-64 uses the same twin-scroll T4 and V-band turbine housings as the G-Series to make the upgrade easy. This housing therefore stays on the engine if the G40-1150 core is later replaced by the GXR40-64.

Do I need to buy a wastegate?

Yes. The housing is free float and has no internal wastegate port, so boost control comes from an external wastegate on the exhaust manifold. Size the gate for the engine and boost target, since a free-flowing 1.06 A/R housing passes a lot of exhaust at high rpm.

Does this listing include the compressor housing?

No. The compressor housing is part of the G40 super core, which Garrett sells separately along with the center section and rotating assembly. This kit covers the turbine side only, which lets the builder pick the exhaust housing size without changing the core.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Garrett G40 Turbine Housing Kit, 1.06 A/R V-Band Inlet and Outlet

Garrett’s G40 Turbine Housing Kit in 1.06 A/R with V-band connections suits single-scroll G40 builds on larger engines, with a stainless steel casting, clamped joints at inlet and outlet, and no internal wastegate. Garrett lists it for the G40-900, G40-1150, G-Series II G40-1000 and G40-1250, and GXR40-64 super cores. It fits a 4.0L to 6.0L engine or a smaller one that revs hard and runs high boost, where a tighter housing would hold back power. On a small engine used mostly at part throttle, the 0.85 or 0.95 will feel far more responsive.

Features

V-band inlet and outlet, stainless steel
Free-float layout for an external wastegate
1.06 A/R, the third size in the V-band G40 Turbine Housing Kit range
Fits the 77mm by 70mm G-Series turbine wheel used on every listed core

Specifications

Garrett part number: 757707-0029
A/R: 1.06
Turbine inlet and outlet: V-band and V-band
Divided inlet: No
Wastegate: External (free float)
Material: Stainless steel
Matching turbine wheel: 77mm inducer and 70mm exducer

Applications

Garrett pairs this G40 Turbine Housing Kit with:

Garrett G40-900: 860777-5003S super core
Garrett G40-1000 G-Series II: 938272-5001S super core, 938271-5001S CHRA
Garrett G40-1150: 860777-5002S super core
Garrett G40-1250 G-Series II: 938272-5002S super core, 938271-5002S CHRA
Garrett GXR40-64 G-XRace: 934173-5005S super core

Notes

An external wastegate is required, because this housing has no internal wastegate
The G40 super core is sold separately
Garrett sets the maximum turbocharger speed at 125,000 rpm for the G40 and G-Series II G40 cores and 109,000 rpm for the GXR40-64; running above it is at the owner’s risk
Garrett also offers 0.85, 0.95 and 1.19 A/R and divided T4 versions
Garrett does not publish a hardware list for this kit; confirm clamps and gaskets before ordering

Frequently Asked Questions

What engines suit the 1.06 A/R V-band G40 Turbine Housing Kit? Larger ones. The 1.06 A/R G40 Turbine Housing Kit suits engines toward the upper part of the 2.0L to 6.0L range Garrett gives for G40 cores, or high-rpm builds on smaller engines. It flows more than the 0.85 and 0.95 sizes, so boost comes in somewhat later.
Is the G40 turbine wheel an upgrade over the GTX4088R? Garrett states that the G-Series turbine aero on the G40 flows 16 percent more than the GTX4088R, and that the Inconel wheel with a 77mm inducer flows up to 43 lbs per minute. This housing is made for that wheel, which sits in the G40 super core sold separately.
Will a GXR40-64 fit if I start with a G40-1150? Yes. Garrett states that the GXR40-64 uses the same twin-scroll T4 and V-band turbine housings as the G-Series to make the upgrade easy. This housing therefore stays on the engine if the G40-1150 core is later replaced by the GXR40-64.
Do I need to buy a wastegate? Yes. The housing is free float and has no internal wastegate port, so boost control comes from an external wastegate on the exhaust manifold. Size the gate for the engine and boost target, since a free-flowing 1.06 A/R housing passes a lot of exhaust at high rpm.
Does this listing include the compressor housing? No. The compressor housing is part of the G40 super core, which Garrett sells separately along with the center section and rotating assembly. This kit covers the turbine side only, which lets the builder pick the exhaust housing size without changing the core.

About Garrett

Garrett Motion has turbocharged engines since 1955, when its T15 was matched to the Caterpillar D9 crawler, and in 1962 a Garrett turbocharger went into the Oldsmobile Jetfire Turbo Rocket, the first turbocharged production car. Garrett has supplied turbocharging in Formula 1 with Scuderia Ferrari, the FIA World Rally Championship and the 24 Hours of Le Mans. It has operated as a stand-alone company since 2018, and its technology is fitted to around 150 million vehicles worldwide.
