What rear brakes come with the MONO6 TA and MONO4r TA Big Brake Kit for RZ34?

Two Racing MONO4r TA calipers over 355mm x 32mm three-piece E-slit rotors on Tufram-coated bells, with brackets, RCP197 pads and lines. The MONO4r TA is a 2,100g pipeless forged monobloc with stainless pistons, built as the rear partner for the MONO6 TA front in this Big Brake Kit for RZ34.

How much does the set save over separate kits?

Endless prices the set below the Racing MONO6 TA front kit and the MONO4r TA rear kit bought separately. It arrives as one order from Endless with matched brackets and lines for both axles, so the whole car is fitted with the TA construction in a single job.

How is the parking brake handled on the Racing MONO4r TA rear set for the RZ34 Z?

The factory parking brake stays. Endless three-piece rear rotors retain it, and this kit runs 355mm x 32mm three-piece rotors at the rear, so the RZ34 Z keeps a working parking brake after the upgrade. Endless two-piece rear rotors are the ones that do not retain it.

Does the Z NISMO use this set?

No. Endless lists the RZ34 NISMO separately, with a dedicated front caliper and rotor size and a narrow rear. This TA set is for the standard RZ34 Z, and we confirm the model on every order before it goes to Endless.

How should the TA set be bedded in?

Endless specifies raising the rotors to around 400 to 500 degrees C without hard stops, then letting them cool naturally to below 100 degrees C. Bed them in on a dry day, because Endless notes that bedding in the rain can stop the pads reaching full performance.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Endless Racing MONO6 TA / Racing MONO4r TA Front and Rear Big Brake Kit for RZ34 Nissan Z with 355mm Rear Rotors

Endless’s Racing MONO6 TA / Racing MONO4r TA Front and Rear Big Brake Kit for RZ34 Nissan Z finishes the rear axle with the pipeless MONO4r TA, the rear-only caliper Endless builds to run behind its MONO6 TA front. At 2,100g it is a forged monobloc with stainless pistons and a 3D-cut surface, gripping a 355mm x 32mm three-piece E-slit rotor on a Tufram-coated bell with the RCP197 pad.

Features

Racing MONO4r TA pipeless forged monobloc rear caliper
2,100g with stainless steel pistons
355mm x 32mm three-piece E-slit rear rotors
RCP197 rear pad shape
Racing MONO6 TA fronts on 370mm rotors
Tufram-coated rotor bells throughout

Specifications

Front caliper: Endless Racing MONO6 TA, six-piston forged monobloc, pipeless
Front caliper weight: 2,880g (Endless USA; Endless Japan lists 3,015g)
Front rotors: 370mm x 34mm, two-piece
Rear caliper: Endless Racing MONO4r TA, four-piston forged monobloc, pipeless
Rear caliper weight: 2,100g
Rear rotors: 355mm x 32mm, three-piece
Pad shapes: RCP121 front, RCP197 rear
Minimum wheel size: 18 inch front, per Endless

What’s Included

Endless Racing MONO6 TA front calipers (2)
Endless Racing MONO4r TA rear calipers (2)
Front and rear Endless brake pad sets
Caliper mounting brackets, front and rear
Front rotors (2), 370mm x 34mm two-piece
Rear rotors (2), 355mm x 32mm three-piece
Brake lines (4)

Applications

Nissan Z: RZ34 | 2023-present

Notes

Front and rear set. Same kit as the listing that leads with the 370mm front rotors
The three-piece rear rotors in this Big Brake Kit for RZ34 retain the factory parking brake
The Racing MONO6 TA front needs an 18 inch wheel at minimum, per Endless
Replace E-slit rotors when the E marks on the face have worn away
Standard RZ34 only; the Z NISMO uses a different Endless set
Made to order in Japan; bleed with DOT4 or higher fluid

Frequently Asked Questions

What rear brakes come with the MONO6 TA and MONO4r TA Big Brake Kit for RZ34? Two Racing MONO4r TA calipers over 355mm x 32mm three-piece E-slit rotors on Tufram-coated bells, with brackets, RCP197 pads and lines. The MONO4r TA is a 2,100g pipeless forged monobloc with stainless pistons, built as the rear partner for the MONO6 TA front in this Big Brake Kit for RZ34.
How much does the set save over separate kits? Endless prices the set below the Racing MONO6 TA front kit and the MONO4r TA rear kit bought separately. It arrives as one order from Endless with matched brackets and lines for both axles, so the whole car is fitted with the TA construction in a single job.
How is the parking brake handled on the Racing MONO4r TA rear set for the RZ34 Z? The factory parking brake stays. Endless three-piece rear rotors retain it, and this kit runs 355mm x 32mm three-piece rotors at the rear, so the RZ34 Z keeps a working parking brake after the upgrade. Endless two-piece rear rotors are the ones that do not retain it.
Does the Z NISMO use this set? No. Endless lists the RZ34 NISMO separately, with a dedicated front caliper and rotor size and a narrow rear. This TA set is for the standard RZ34 Z, and we confirm the model on every order before it goes to Endless.
How should the TA set be bedded in? Endless specifies raising the rotors to around 400 to 500 degrees C without hard stops, then letting them cool naturally to below 100 degrees C. Bed them in on a dry day, because Endless notes that bedding in the rain can stop the pads reaching full performance.

About Endless

Endless was founded in 1986, when Isao Hanazato began developing brake pads out of his own racing experience, and the company builds its friction material, rotors, calipers and brake fluid in Saku City, Nagano. It has run its own team since 1991, in the All Japan F3 Championship and the Mirage Cup, and by 2017 had supplied brake fluid to Formula 1 for fifteen consecutive years. The pads supplied in each kit are Endless compounds, so caliper and friction material come from the same company.
