What rear caliper comes in the Racing MONO6 and MONO4r Big Brake Kit for RZ34?

The Racing MONO4r, the rear-only caliper in the Endless Racing MONO family. It is a 2,260g forged monobloc with two 27mm and two 32mm pistons and a 15mm RCP147 pad, running on 355mm x 32mm three-piece E-slit rotors in this Big Brake Kit for RZ34.

What does the set cost against separate kits?

Endless prices the set below the Racing MONO6 front kit and the Racing MONO4r rear kit added together. It arrives as one order with matched brackets and lines for both axles, so the front and rear of the car are fitted with Racing MONO calipers in the same job.

Is there a newer version of the rear caliper coming?

Yes. Endless announced on 30 September 2026 that it is redesigning the Racing MONO4r, with larger rotor options and deliveries from around April 2027. The current caliper is sold until stock runs out, and we will confirm which version your set receives.

Does the parking brake still work on the Racing MONO4r rear set for the RZ34 Z?

The factory parking brake stays. Endless three-piece rear rotors retain it, and this kit runs 355mm x 32mm three-piece rotors at the rear, so the RZ34 Z keeps a working parking brake after the upgrade. Endless two-piece rear rotors are the ones that do not retain it.

How should the brakes be bedded in?

Endless specifies raising the rotors to around 400 to 500 degrees C without hard braking, then letting them cool naturally to below 100 degrees C. Do it in dry weather, as Endless notes bedding in the rain can keep the pads from reaching their full performance.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Endless Racing MONO6 / Racing MONO4r Front and Rear Big Brake Kit for RZ34 Nissan Z with 355mm Rear Rotors

Endless’s Racing MONO6 / Racing MONO4r Front and Rear Big Brake Kit for RZ34 Nissan Z gives the rear axle a forged monobloc of its own. The Racing MONO4r is the EC4606N, a 2,260g rear-only caliper with two 27mm and two 32mm pistons and a 15mm RCP147 pad, clamping a 355mm x 32mm three-piece E-slit rotor. It is the rear Endless pairs with the Racing MONO6 front in this set. Endless has announced a redesigned MONO4r from around April 2027, and the current caliper sells until stock runs out.

Features

EC4606N Racing MONO4r forged monobloc rear caliper
Pistons of 27mm and 32mm, two of each
355mm x 32mm three-piece E-slit rear rotors
15mm RCP147 rear pad
Racing MONO6 front calipers on 370mm rotors
Monobloc construction at all four corners

Specifications

Front caliper: Endless Racing MONO6, six-piston forged monobloc
Front caliper weight: 2,930g
Front piston sizes: 27mm x 2, 32mm x 2, 38mm x 2
Front rotors: 370mm x 34mm, two-piece
Rear caliper: Endless Racing MONO4r, four-piston forged monobloc
Rear caliper weight: 2,260g
Rear piston sizes: 27mm x 2, 32mm x 2
Rear rotors: 355mm x 32mm, three-piece
Pad shapes: RCP121 front, RCP147 rear
Minimum wheel size: 18 inch front, per Endless

What’s Included

Endless Racing MONO6 front calipers (2)
Endless Racing MONO4r rear calipers (2)
Front and rear Endless brake pad sets
Caliper mounting brackets, front and rear
Front rotors (2), 370mm x 34mm two-piece
Rear rotors (2), 355mm x 32mm three-piece
Brake lines (4)

Applications

Nissan Z: RZ34 | 2023-present

Notes

Front and rear set. Same kit as the listing that leads with the 370mm front rotors
Endless announced a redesigned MONO4r on 2026-09-30, with deliveries from around April 2027; current stock sells until gone
The Racing MONO6 front needs an 18 inch wheel at minimum; check both axles against the Endless template
The three-piece rear rotors in this Big Brake Kit for RZ34 retain the factory parking brake
Standard RZ34 only, not the Z NISMO
Made to order in Japan; use DOT4 or higher fluid

Frequently Asked Questions

What rear caliper comes in the Racing MONO6 and MONO4r Big Brake Kit for RZ34? The Racing MONO4r, the rear-only caliper in the Endless Racing MONO family. It is a 2,260g forged monobloc with two 27mm and two 32mm pistons and a 15mm RCP147 pad, running on 355mm x 32mm three-piece E-slit rotors in this Big Brake Kit for RZ34.
What does the set cost against separate kits? Endless prices the set below the Racing MONO6 front kit and the Racing MONO4r rear kit added together. It arrives as one order with matched brackets and lines for both axles, so the front and rear of the car are fitted with Racing MONO calipers in the same job.
Is there a newer version of the rear caliper coming? Yes. Endless announced on 30 September 2026 that it is redesigning the Racing MONO4r, with larger rotor options and deliveries from around April 2027. The current caliper is sold until stock runs out, and we will confirm which version your set receives.
Does the parking brake still work on the Racing MONO4r rear set for the RZ34 Z? The factory parking brake stays. Endless three-piece rear rotors retain it, and this kit runs 355mm x 32mm three-piece rotors at the rear, so the RZ34 Z keeps a working parking brake after the upgrade. Endless two-piece rear rotors are the ones that do not retain it.
How should the brakes be bedded in? Endless specifies raising the rotors to around 400 to 500 degrees C without hard braking, then letting them cool naturally to below 100 degrees C. Do it in dry weather, as Endless notes bedding in the rain can keep the pads from reaching their full performance.

About Endless

Endless was founded in 1986, when Isao Hanazato began developing brake pads out of his own racing experience, and the company builds its friction material, rotors, calipers and brake fluid in Saku City, Nagano. It has run its own team since 1991, in the All Japan F3 Championship and the Mirage Cup, and by 2017 had supplied brake fluid to Formula 1 for fifteen consecutive years. The pads supplied in each kit are Endless compounds, so caliper and friction material come from the same company.
