What does the rear of the 6POT and BIG4 Big Brake Kit for RZ34 add?

Rear calipers and rotors sized to match the front. The forged BIG4 four-piston caliper and its 355mm three-piece rotor replace the factory rear brakes, so the rear axle can take its share of the work on track rather than leaving the front half of the Big Brake Kit for RZ34 to do it alone.

Do the front and rear use the same pads on the Racing BIG4 rear set for the RZ34 Z?

Yes. The 6POT front caliper and the Racing BIG4 rear caliper both use the RCP052 pad shape, so one compound decision and one spare pad part number cover the whole car. That is one of the practical advantages of this pairing.

What about the parking brake?

The factory parking brake stays. Endless three-piece rear rotors retain it, and this kit runs 355mm x 32mm three-piece rotors at the rear, so the RZ34 Z keeps a working parking brake after the upgrade. Endless two-piece rear rotors are the ones that do not retain it.

How much does the set save over buying the kits separately?

Endless prices the set below the 6POT front kit and the Racing BIG4 rear kit added together, so buying both axles at once costs less. It also arrives as one order from Endless, with matched brackets and brake lines for the front and rear of the car.

How should the Endless set be bedded in?

Endless specifies bringing the rotors to roughly 400 to 500 degrees C without hard stops, then letting the brakes cool naturally to below 100 degrees C. Do it in dry weather, since Endless notes that bedding in the rain can keep the pads from reaching their full performance.

Description

Additional Info

Shipping policy

BP PRICING DIFFERENCE

Reviews

Product Inquiry

Description

Endless 6POT / Racing BIG4 Front and Rear Big Brake Kit for RZ34 Nissan Z with 355mm Rear Rotors

Endless’s 6POT / Racing BIG4 Front and Rear Big Brake Kit for RZ34 Nissan Z is the set that brings the Z’s rear brakes up to the standard of an Endless front axle. The rear runs the forged two-piece EC470 BIG4, a 3,486g caliper with 27mm and 32mm pistons over a 355mm x 32mm three-piece curving slit rotor, the caliper Endless created to balance its six-piston fronts. Up front, the 6POT and its 370mm rotor complete the set.

Features

Racing BIG4 rear caliper, forged two-piece, four pistons
355mm x 32mm three-piece curving slit rear rotors
6POT front caliper with stepped 27mm to 38mm pistons
370mm x 34mm two-piece front rotors
One RCP052 pad shape for both axles
Blue anodise calipers all round

Specifications

Front caliper: Endless 6POT, six-piston forged two-piece
Front caliper weight: 3,280g
Front piston sizes: 27mm x 2, 32mm x 2, 38mm x 2
Front rotors: 370mm x 34mm, two-piece
Rear caliper: Endless Racing BIG4, four-piston forged two-piece
Rear caliper weight: 3,486g
Rear piston sizes: 27mm x 2, 32mm x 2
Rear rotors: 355mm x 32mm, three-piece
Pad shapes: RCP052 front, RCP052 rear
Minimum wheel size: 17 inch front, per Endless

What’s Included

Endless 6POT front calipers (2)
Endless Racing BIG4 rear calipers (2)
Front and rear Endless brake pad sets
Caliper mounting brackets, front and rear
Front rotors (2), 370mm x 34mm two-piece
Rear rotors (2), 355mm x 32mm three-piece
Brake lines (4)

Applications

Nissan Z: RZ34 | 2023-present

Notes

Front and rear in one kit. This Big Brake Kit for RZ34 is the same set as the listing that leads with the 370mm front rotors
The three-piece rear rotors retain the factory parking brake
The standard RZ34 only. The Z NISMO takes a different Endless set
Check wheel clearance against the Endless template for both axles
Use DOT4 or higher fluid and bed the pads in on a dry day
Made to order by Endless in Japan; lead time is confirmed after ordering

Frequently Asked Questions

What does the rear of the 6POT and BIG4 Big Brake Kit for RZ34 add? Rear calipers and rotors sized to match the front. The forged BIG4 four-piston caliper and its 355mm three-piece rotor replace the factory rear brakes, so the rear axle can take its share of the work on track rather than leaving the front half of the Big Brake Kit for RZ34 to do it alone.
Do the front and rear use the same pads on the Racing BIG4 rear set for the RZ34 Z? Yes. The 6POT front caliper and the Racing BIG4 rear caliper both use the RCP052 pad shape, so one compound decision and one spare pad part number cover the whole car. That is one of the practical advantages of this pairing.
What about the parking brake? The factory parking brake stays. Endless three-piece rear rotors retain it, and this kit runs 355mm x 32mm three-piece rotors at the rear, so the RZ34 Z keeps a working parking brake after the upgrade. Endless two-piece rear rotors are the ones that do not retain it.
How much does the set save over buying the kits separately? Endless prices the set below the 6POT front kit and the Racing BIG4 rear kit added together, so buying both axles at once costs less. It also arrives as one order from Endless, with matched brackets and brake lines for the front and rear of the car.
How should the Endless set be bedded in? Endless specifies bringing the rotors to roughly 400 to 500 degrees C without hard stops, then letting the brakes cool naturally to below 100 degrees C. Do it in dry weather, since Endless notes that bedding in the rain can keep the pads from reaching their full performance.

About Endless

Endless was founded in 1986, when Isao Hanazato began developing brake pads out of his own racing experience, and the company builds its friction material, rotors, calipers and brake fluid in Saku City, Nagano. It has run its own team since 1991, in the All Japan F3 Championship and the Mirage Cup, and by 2017 had supplied brake fluid to Formula 1 for fifteen consecutive years. The pads supplied in each kit are Endless compounds, so caliper and friction material come from the same company.
