AL13 Flow+Technik Series FR80 Wheel

AL13’s Flow+Technik Series pairs a modern multi-spoke look with lightweight performance and tight manufacturing standards. Each wheel starts as a forged monoblock and is engineered for strength, lower mass, and a pronounced concave profile, then finished with detailed CNC work and hands-on refinement. This series is designed to keep the face open for brake cooling and caliper clearance while maintaining the rigidity needed for daily driving and aggressive use. Every wheel is machined from 6061-T6 forged aluminum, run through extended milling cycles, and verified against AL13 run-out specs before final assembly.

AL13 Manufacturing

• Engineering: AL13 Wheels are developed end to end in Southern California with an emphasis on precise design, disciplined engineering, and skilled craftsmanship focused on long-term performance. With more than 70 years of combined forged wheel experience in-house, each set is controlled through the full process and validated with FEA testing to balance weight, durability, and strength.

• Material: APP Forged Wheels use a one-piece 6061-T6 aerospace forging method to create a strong, lightweight wheel without porosity, welds, or joint lines. Heat and pressure reshape the aluminum into a forged grain structure, then spin-forging strengthens the rim by aligning grain flow with real operating loads for higher integrity and durability.

• Profile: Lathe turning shapes the forging from both sides to build concavity while pulling out as much weight as possible. More than 70 percent of the original material is removed during this stage to maximize strength-to-weight.

• Milling: After profiling, each forging moves to CNC milling where the final design is cut using dedicated tooling and programmed tool paths, with machining cycles that can take up to eight hours per wheel. The raw milled aluminum is then hand-finished through filing, deburring, buffing, and ceramic bead high-luster polishing, followed by a detailed inspection before any coating is applied.

• Prep: Brushing and polishing are the most time-intensive parts of the finish process and are available as upgrades across the AL13 lineup. Brushing highlights the forged grain, while touch-less high-luster ceramic polishing delivers a mirror-style surface.

• Finishing: AL13 finishes and assembles each wheel to strict standards, working with selected finishing partners in Brisbane, Tokyo, and Hamburg for brushed or polished bases and transparent powder coats in gloss, satin, or textured options. During assembly, run-out is checked and wheels must measure under 0.010 inch, with many testing closer to 0.007 inch to reduce the chance of high-speed vibration. Hardware is torqued using calibrated Digital Snap-On torque wrenches, then marked and signed off by the assembly team before packaging.


Finishes

• AL13 Wheels offers two finish lines, Solid and Premium Transparent, each available in a wide range of colors and sheen options. Choices include gloss, matte, satin, and textured finishes depending on the look and maintenance you want.
  • Solid Colors: Available with gloss, satin, or textured clear coat options, with optional 2-tone finishing in brushed or polished.
    • Bronze
    • Dark Grey
    • Grand Prix White
    • Precision Black
    • Race Gold
    • Silver
    • Titanium
  • Transparent Colors: Available in gloss or satin, with brushed, high luster polished, or stone bases, plus optional 2-tone finishing in brushed or polished.
    • Cali Gold
    • Carbon Red
    • Champion Bronze
    • Clear
    • Combustion Blue
    • Liquid Bronze
    • Shadow Black
    • Shadow Grey
    • Shadow Silver

Features

• Aero-space grade 6061 T6 forged aluminum material
• 6061-T6 aluminum rim halves
• Lightweight monoblock configuration
• Tailor-made and built-to-order for specific vehicle fitment
• Milled back-side pocketing for un-sprung mass reduction, promotion of cornering dynamics, stopping power and acceleration
• 2-piece forged carbon fiber center-caps come standard
• Optional Floater Cap with Lug Covers and/or Valve Stems at additional charge
• Boundless component finishing options

Specifications

• Wheel Series: Flow+Technik Series
• Wheel Model: FR80
• Wheel Material / Construction: 6061-T6 forged aluminum
• Wheel Configuration: Monoblock 1-piece
• Diameters:
  • 19″
  • 20″
  • 21″
  • 22″
  • 24″
• Widths:
  • 8″
  • 8.5″
  • 9″
  • 9.5″
  • 10″
  • 10.5″
  • 11″
  • 11.5″
  • 12″
  • 12.5″
  • 13″
• Offsets: Custom
• Bolt Patterns: 5-lug or 6-lug
• Centerlock: No

Notes

• AL13 Wheels are all sold individually
• 6-lug bolt patterns may result in changes to spoke designs to accommodate additional lug pocketing
• AL13 Wheels are individually crafted from the finest materials to your individual spec. There are no “off the shelf” AL13 wheels and as such, a lead time of a few weeks is to be expected once your spec has been finalized. The Bulletproof Team will serve as your concierge throughout the entire process to ensure you get the perfect wheel for your application.
• AL13 also offers 2-Tone Finishing across all color options. Due to the sheer number of possible combinations, these 2-tone configurations may not be shown as selectable options, but they are available to order. If you’re interested in pricing please contact us and we’ll help you spec the right finish package.

About AL13 Wheels

As a renowned leader in the manufacture of performance, luxury and SUV wheels located in Anaheim California USA, AL13 is known throughout the industry for its commitment to priding quality craftsmanship. Utilizing only metals and materials like 6061 T6 aluminum, Titanium alloys, 5454 H34 steel alloy; Acrylics Ceramics & Carbon Fiber fibers with their advanced machining techniques producing superior custom finishes. With experts that account for fitments; tracking systems/standards backed by an impeccable Quality Control team assures long-term dynamic performance along with product integrity from this world’s most distinctive wheel brand.
